Automatically Warping Sampling Machine

automatically warping sampling machine

This machine can swiftly and accurately measure small samples of textiles and is a new type machine jointly developed by our company and Thailand agent who work for muller more than 20 years. It is convenient for adjusting parameters, and the samples enjoy the same style as the manufactured products. It is applied to the weaving of test samples of cotton, wool, silk, flax, chemical fiber and blended textile.

Technical Parameters and Performance Index of the Machinery
Width: 12 inches, 20 inches, 24 inches
Let-off: Adopting step motor for active elecronic warp introduction(digit display control let-off is option), have two shaft or three shaft choose
Take-up: Adopting step electronic machine for rolling with the weft density range of 10-300 filaments/inch
Shed: 20-page electronic pneumatic-controlled mouth opening facility(including 20-page frames), or 24-pageframes
Color Selection: 8-color electronic pneumatic-controlled weft selection
Beat-up: Adjustable pneumatic beating up. AC seno motor control cam beating up
Weft introducing method: Via pneumatic-controlled single rigid rapier or AC seno motor-controlled
Yarn: 5-500tex
Machine Speed: 35-50rpm
Gas: 0.45-0.75MPa, 0.25L/min(12'), 0.56L/rain(20')
Installation sie: 660*1150*1100mm(L, W, H)(12')
860*1150*1100mm(L, W, H)(20")

Central control board
Hardware: P4 C2.4G CPU/256M EMS memory/40G hard disk/mouse/15 inch liquid crystal monitor, S7-200 PLC
Software: WINDOWS2000 Operational System with textile designing software
Installation size: 698*660*1000mm(L, W, H) (12')
698*750*1000mrn(L, W, H)(20')
