Competitive Price STA Graphite Crucibles for Melting Metals
US$ 10 - 220
MOQ: 2 Pieces
Key Specifications
Get Latest Price
Type:
Refractory
Application:
used for refractory
Height:
As customers' requests or drawings
Payment & Shipping
Payment Methods:
Port of Shipment:
any port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
STA High Pure and Density Graphite Crucible With Factory PriceUS$ 3 - 90MOQ: 10 Pieces -
STA High Quality Melting Graphite Crucible for IndustrialUS$ 3 - 90MOQ: 10 Pieces
-
STA High Melting Graphite Crucible for SaleUS$ 3 - 90MOQ: 10 Pieces
-
STA CE Quality Graphite Sic Crucible for MeltingUS$ 3 - 90MOQ: 10 Pieces
-
STA Gold and Silver Melting Sic Graphite CrucibleUS$ 3 - 90MOQ: 10 Pieces
Type
Refractory
Application
used for refractory
Height
As customers' requests or drawings
Composition
High Pure
Top Diameter
As customers' requests or drawings
Bottom Diameter
As customers' requests or drawings
Place of Origin
Henan, China
Brand Name
STA
Model Number
STA-C002
Specifications
graphite crucibles for melting metals1.temp up to 1800
2.do according to your order
3.Excellent Oxidation Resistance
STA graphite crucibles for melting metals
1.Our company is private limited liability company, approved by the State Administration for Industry.
2.Our company pay attention to quality and credibility, have pragmatic and innovative spirit of enterprise, the company's principle is "quality is life of enterprise, integrity is the fundamental of the enterprise.”
A crucible is a container used to hold metal for melting in a furnace and it is needed to withstand the extreme temperatures.
Graphite crucible can withstand the high temperature, and has good resistance to chemical erosions and thermal shock. Especially graphite crucible is ideal for the melting of aluminum, copper and etc.
SPECIFICATION
| item | data |
| open porosity | <0.1% |
| bending strength | 250Mpa(20centigrade), 280Mpa(1200centigrade) |
| modulus of elasticity | 330Gpa(20centigrade), 300Gpa(1200centigrade) |
| thermal conductivity | 45W/m.k(1200centigrade) |
| coefficient of thermal expansion | 4.5K-1*10-6 |
| Mohs hardness | 13 |
| Catalogue Number | Approx Capacity(kg) | Top Dia | Bottom Dia | Height | |||
| STA-1 | 1 | in | mm | in | mm | in | mm |
| 2.75 | 70 | 1.96 | 50 | 3.14 | 80 | ||
| 2 | 2 | in | mm | in | mm | in | mm |
| 3.14 | 80 | 2.16 | 55 | 3.74 | 95 | ||
| 4 | 4 | in | mm | in | mm | in | mm |
| 4.33 | 110 | 3.14 | 80 | 5.11 | 130 | ||
| 6 | 6 | in | mm | in | mm | in | mm |
| 4.72 | 120 | 3.26 | 83 | 5.9 | 150 | ||
| 8 | 8 | in | mm | in | mm | in | mm |
| 5.51 | 140 | 3.7 | 94 | 6.69 | 170 | ||
| 10 | 10 | in | mm | in | mm | in | mm |
| 6.29 | 160 | 4.33 | 110 | 7.08 | 180 | ||
| 12 | 12 | in | mm | in | mm | in | mm |
| 7.08 | 180 | 4.52 | 115 | 9.44 | 240 | ||
| 16 | 16 | in | mm | in | mm | in | mm |
| 8.26 | 210 | 5.51 | 140 | 10.23 | 260 | ||
| 20 | 20 | in | mm | in | mm | in | mm |
| 8.46 | 215 | 6.29 | 160 | 10.23 | 260 | ||
| 25 | 25 | in | mm | in | mm | in | mm |
| 8.26 | 210 | 5.51 | 140 | 10.23 | 260 | ||
| 30 | 30 | in | mm | in | mm | in | mm |
| 8.46 | 215 | 6.29 | 160 | 10.23 | 260 | ||
| 35 | 35 | in | mm | in | mm | in | mm |
| 9.05 | 230 | 6.69 | 170 | 10.63 | 270 | ||
| 40 | 40 | in | mm | in | mm | in | mm |
| 9.84 | 250 | 7.08 | 180 | 11.41 | 290 | ||
| 50 | 50 | in | mm | in | mm | in | mm |
| 10.43 | 265 | 7.28 | 185 | 11.81 | 300 | ||
| 60 | 60 | in | mm | in | mm | in | mm |
| 10.63 | 270 | 7.67 | 195 | 13.18 | 335 | ||
