Specification
1. Refractory ceramic fiber blanket
2. Low thermal conductivity
3. low thermal capacity
4. Good heat insulation effect
Insulation materials Ceramic Fiber Bulk/Blanket
Product grade for Refractory ceramic fiber blanket
| Grade | 1260 Blanket | 1430Blanket | 1500Blanket | 1600 Blanket | |
| Classification Temperature | ° C | 1260 | 1430 | 1500 | 1600 |
| Max Working Temperature | ° C | 1100 | 1280 | 1350 | 1580 |
| Melting Point | ° C | 1760 | 1700 | 1760 | - |
Chemcial Composition for Refractory ceramic fiber blanket
| Grade | 1260 Blanket | 1430Blanket | 1500Blanket | 1600 Blanket | |
| Al2O3 | % | 47.1 | 35 | 40 | 72 |
| SiO2 | % | 52.3 | 49.7 | 57.8 | 28 |
| ZrO2 | % | - | 15 | - | - |
| Cr2O3 | % | - | - | 2.0 | - |
STA Refractory ceramic fiber blanket is a kind of continuous cotton tiled fiber blanket made by pure material melted in 2300 degrees of high temperature upon tossing and needling,which has high tensile strength,sound capability against chemical erosion and is smooth in surface.The fiber blanket is free from organic adhesive.
Product Images
Physical Properties for Refractory ceramic fiber blanket
| Grade | 1260 Blanket | 1430Blanket | 1500Blanket | 1600 Blanket | |||||||
| Density | Kg/m3 | 96 | 128 | 160 | 96 | 128 | 160 | 128 | 160 | 128 | |
| Thermal Conductivity W/(m. K) |
400 | ° C | 0.12 | 0.10 | 0.08 | ||||||
| 600 | ° C | 0.17 | 0.15 | 0.14 | 0.15 | 0.14 | 0.13 | 0.13 | 0.12 | 0.09 | |
| 800 | ° C | 0.25 | 0.24 | 0.23 | 0.24 | 0.23 | 0.21 | 0.21 | 0.18 | 0.13 | |
| 1000 | ° C | 0.32 | 0.29 | 0.27 | 0.27 | 0.25 | 0.19 | ||||
| Linear Shrinkage(° Cx24H) | % | 1100 ° C---1.8 | 1300 ° C---1.5 | 1400 ° C---2.0 | 1500 ° C---1.0 | ||||||
| Color | White | White | Blue-green | White | |||||||
Avaiable Size for Refractory ceramic fiber blanket
| Grade | 1260 Blanket | 1430Blanket | 1500Blanket | 1600 Blanket | ||||||||
| Density | Kg/m3 | 96 | 128 | 160 | 96 | 128 | 160 | 128 | 160 | 128 | ||
| Thickness | Width | Length | ||||||||||
| 6 | 610 | 7200 | mm | √ | √ | X | X | X | X | X | X | X |
| 13 | 610 | 7200 | mm | √ | √ | X | √ | √ | X | X | X | X |
| 20 | 610 | 7200 | mm | √ | √ | √ | √ | √ | √ | √ | √ | X |
| 25 | 610 | 7200 | mm | √ | √ | √ | √ | √ | √ | √ | √ | 25x620x3600 |
| 50 | 610 | 7200 | mm | √ | √ | √ | √ | √ | √ | √ | √ | X |
Property of Refractory ceramic fiber blanket
√ Double needled blanket
√ Light weight
√ Excellent chemical stability
√ Excellent thermal stability
√ Excellent tensile strength
√ Low thermal conductivity
√ Low shrinkage and heat storage
√ Shorter heat up and cool down time
√ Resilience and resistance to thermal shock
√ Flexible and easy to cut or install
√ Without organic binder and Asbestos free
Applications of Refractory ceramic fiber blanket
1. ceramic fiber blanket Filling insulation and joint sealing
2. ceramic fiber blanket Back-up lining for industrial furnaces
3. ceramic fiber blanket Fireproof materials for construction
4. ceramic fiber blanket High temperature materials for filtration
5. ceramic fiber blanket Raw materials for further producing, such as modules
Our Market
As the factory of more than 30 years experience, we are always aiming at being a leading brand in the refractory insulation industry around the world.
OEM Service
1.Your inquiry related to our products or prices will be replied within 12 hours.
2.Help to solve the problem in the application or selling period.
3.Guatantee samples quality same as mass production quality.
4.Adhering to the business philosophy"mutual trust,mutual benefit,mutual profit,faith oriented".
Our Certification
Why choose us
Competitive Price
STA is a professional manufacturer of refractory products
Good Quality
STA have a senior research & development team and stric QC.
Fast Delivery Time
A large scale of product lines ensure the large quantity goods.
If you need to buy Refractory ceramic fiber blanket,please contact
Lily
STA Universe Group
Add: # 827, KeXue Rd, High tech park, '
Zhengzhou, Henan, China.
Tel: +86-371-55180399 / 55521077
Fax: +86-371-55132176
Skype: stad(at)
live:stad_25
Trademanager:cn1500473177
E-mail: stad(at)
Web:
1. Are you a manufacturer or trading company ?
We are professional manufacturer in China, and have in this line for more than 30 years. Also we operate other insulation refractory materials.
2. Would it be possible for us to visit your factory?
Sure, we welcome you at any time! Seeing is believing.
3. Which payment terms are you accept?
T/T, LC, Western Union, Money Gram are available for us.
4. After an order is placed, when to deliver?
7-15 working days after received advance payment.
5. Is your company accept customization?
Yes, we are. And we also accept OEM service, cause we have our own factory and excellent technical team. We believe that can achieve customer satisfaction.
6. How to solve the quality problems?
If the products are not conform to customer samples or have quality problems, our company will be responsible to make compensation for it.
