Docan Fast Speed Canvas Roll to Roll UV Printing Machine R3300

Name: Docan Fast Speed Canvas Roll to Roll UV Printing Machine R3300
Brand: DOCAN
SKU: 111344483

US$ 30,000 - 140,000 MOQ: 1 Set

Key Specifications

Condition:

New

Plate Type:

Flatbed Printer

Place of Origin:

Shanghai, China

Shanghai Docan Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Plate Type Flatbed Printer

Place of Origin Shanghai, China

Brand Name DOCAN

Model Number R3300

Usage Other

Automatic Grade Automatic

Voltage 220V

Gross Power 8KW

Dimensions(L*W*H) 5.6*1.5*1.72m

Weight 3630KG

Certification CE,ISO

After-sales Service Provided Engineers available to service machinery overseas

Production speeds up to78m2/h

Double sided backlit printing option

Media handling system supports rolls up to 300kg

Prints on viny,banner,films,paper&fabrics

Visible resolution up to 1440dpi

Fast curing,environmentally friendly UV inks

Maximum printing width of 3.2m

Simultaneous printing on multiple rolls

Model	DOCAN R3300
Print head	KM-1024-14PL/RICOH GEN5
Catagory	UV series
Print Technology	Drop-on-demand Piezo Electic
Nozzle Technology	Piezoelectric Inkjet
Print head controls	Print head temperature and voltage are software adjustable
Cloth feeding system	Automatic rotary motor can be driven to achieve optimal tension distributing
Cloth collecting system	Automatic motor rotatingφ 35cm
Material accepted	Roll to roll
Ink Characteristics	UV curing ink
Ink Reservoir	Refillable on the fly while printing/ 2L
Drying system	UV lamp
Rip software	Photoprint/ Onyx/ Caldrea
Color Management	Icc Based Color, Curves Adjustment, Density Adjustment
File Format	Tiff, Jpeg, Postscript 3, Eps and Pdf
Power supply	50/60hz 220v ( 10%) >30A
Operation Environment	Temperature 20c to 28c degrees
Humidity	40% to 70%
Media width	3.3m
Printing size	3.2m
Media thickness	2mm
Nozzle Number	4/5/6/7/8/10/12/14/16pcs
Resolution	360dpi360dpi 360dpi720dpi
	720dpi360dpi 720dpi720dpi
	720dpi1440dpi 1440dpi1440dpi
Printing speed	In Draft mode up than 65sq.m/h (8 heads)
	In Standard mode up than 45sq.m/h ( 8 heads)
	In High resolution mode up than 36sq.m/h (8 heads)
Colors	8 colors( double CMYK) to 14 pcs(double CMYK+LC+LM+W)
Outdoor life	3 years(use Docan ink)
Dimensions	5.601.501.72m
Weight	3630KG
