Specifications
1no printing plate,pre-treating surfacecoated film2high resolution high speed
4wide size
5high costeffective
3no pollutio
The main features and advantages of Docan large-format UV digital printer for sheet & coil material(UV2510)
First thanks for your inquiring our UV printers.We are professional manufacturer of UV printers in China.Our company was established in 2005 and now our products have been exported to more than 30 countries such as USA,Brazil,Mexico,Chile,UK,Spain,Finland,Portugal.Italy.Czech,Turkey,Russia,Poland,Ukraine,Monglia,India,Philippines,Indonesia etc.Now I’ll give you a specific introduction on the general features and specification of our UV printer to make you find more profit modes.
10 benefits of our large-fomat UV printer for your Business
1. Print on a far broader range of substrates. Unlike many other printing processes, UV-curing bonds the ink to almost any surface from hand-made canvas and leather to concrete, wood, metal, plastic,ceramic tiles glass,ceiling,aluminum sheet, acrylic paper ,foam ,PVC ,corrugated cardboard,sticky note, reflective film.
2. Wider printed material size:Effective printing size:2.5m+unlimited length Printed material thickness:less than 60mm
3. Open the door to a new world of creative possibilities. The versatility of UV printers offers huge creative potential for your business and clients. Use UV printers for indoor, outdoor and backlit signs, rigid paperboard packing ,leather,textile printing ,artware , decoration, art glass, sign industry, exhibition industry, furniture ,POPs, posters, vehicle wraps, building wraps, cabinets, etc.
4. Say goodbye to pre-treating surfaces,printing plate and coated films or papers. Direct print on printed substrates.Cost of single piece and batch printing is the same,So it’s very suitable for single piece and small-lot production, sample printing and image effects stimulation.
5. Faster drying time means faster production speeds. Unlike water-based and solvent-based ink,UV curing ink can converted to a polymer immediately under the irradiation of UV light.With our UK Primarc UV lamp,the ink drying time is only 0.2s,which translates into high operating speeds
6. Print multiple color layers at the same time. UV flatbed printers keep the media stationary and instead the printhead carriager, which holds the print heads, moves over the media. This together with Stagger printhead arrangement allows for multiple layers of high-speed printing simultaneously including white ink or spot varnishes on highlighted areas of the media
7. Better color saturation on solids and substrates. Advanced color control software and high-performance UV curing ink bring you photo-quality printing effect.
8. Final printed product has higher resistance to fading, rubbing, moisture and heat. Because the ink has been converted to a polymer and already exposed to maximum levels of UV light it’s wonderfully durable and resistant
9. Healthier for your workplace and the planet. Unlike solvent-based inks,UV curing inks haven't volatile organic compounds (VOCs) emitting into the atmosphere,which creates a more pleasant and safer work environment for your staff.
10. You’ll even save on your electricity bill. Conventional large-format printers use heat to cure the ink and consume a large amount of power to create this heat,while our UV printers use either mercury/quartz or LED lights for curing, rather than heat.Our high-performance and long-life UV lamp from UK Primarc has the higher level of curing efficiency and at least1000-hour life.The total power of the printer is less than 8KW.
| Specification | |
| Product Model | Docan UV2510 flatbed &roll-roll hybrid printer |
| Printhead Technology | Drop-on demand piezo electric |
| Printhead control | Printhead temperature and voltage are software adjustable |
| Printhead Type | Konica KM512-14PL(Konica KM1024MHB optional) |
| Printhead Number | 4/5/6/7/8/10/12/14/15/16 |
| Ink Characteristics | UV Curing Ink |
| Ink Type | Japan Toyo or UK Sunjet |
| Ink Reservoir | Reliable on the fly while printing/1000ml |
| Color Control | ICC based color,curves and density adjustment |
| color Type& printhead arrangement |
KM512-14PL KM1024MHB-14PL CMYK/CMYKLcLm CMYK/CMYKLcLm CMYKW/CMYKLcLmW CMYKW/CMYKLcLmW CMYK*2/CMYKLcLm*2 CMYK*2/CMYKLcLm*2 CMYKW*2/CMYKLcLmW*2 CMYKW*2 CMYK*3 |
| Pringting Size | Material width 2.5m+unlimited length |
| Media Thickness | less than 60mm |
| Printing Resolution &Speed |
720x720DPI(4pass) 40Sq.m/h(8 KM512 printheads) 720x1080DPI(6pass) 28Sq.m/h(8 KM512 printheads) 720x1440DPI(8pass) 20Sq.m/h(8 KM512 printheads) 1080x1440DPI(12pass) 12Sq.m/h(8 KM512 printheads) |
| Life of printed image | 5 years(outdoor),10year(indoor) |
| File Format | TIFF,JPEG,Postscript,EPS,PDF |
| RIP Software | Photoprint 10 |
| Power Supply | 220V 50/60Hz(10%) less than 20A |
| Operation Enviroment | Temperature 20 to 30,Humidity 40% to 60% |
| Equipment Dimension | 4.89x2.89x1.81m |
| Equipment Weight | 3125kg |
| Warranty | 1 year(exclude printhead,ink pump,ink filter) |
| After-sale service | Free installation,debugging,training 24-hour online realtime technology support |
Payment terms: 30%T/T IN ADVANCE, 70% AGAINST COPY OF B/L
Shipping terms: within 20 working days after receiving 30% deposit.Shipping Port:Port of Shanghai
Japan Konica KM512-14PL or KM1024MHB-14PL printhead
Japan Toyo specialized UV curable ink
