Specifications
UV Flatbed Printer1. Printing size: 2.05m*3.2m.
2. Max. printing thickness: 100mm.
3. Print on glass, acrylic, pvc, etc.
UV Flatbed Printer
Detailed Product Description
Docan M10 flat bed UV printer adpots Japan Konica1024-14PL/42PL head, supporting you high speed and resolution of printing
Specification of uv flat bed printer
1) UV Inkjet Flatbed Printer
2) Konica Minolta printhead
3) 360dpi*360dpi-1440dpi*1440dpi
4) C,M,Y,K or C,M,Y,K,LC,LM + White colors
5) CE Certificate
Perfect quality along with competitive price
Since we are a few manufacturers of UV flatbed printer in China with many years production experience, we can provide the printer with excellent performance & direct price. You will enjoy our one-stop survice.
Higher speed plus higher resolution
Konica printhead with 1024-14PL/42pl nozzle is used to support you with high speed printing and higher resolution(Max resolution can be up to 1440dpi*1440dpi
More application
Application areas includs:Decoration industry, glass industry;Sign industry;Exhibition industry;Leather textile printing industry, etc.
Printed materials could be:Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board & flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, and so on.
Equipment model |
M10 |
Print technology |
Drop-on-demand piezo electric |
Print head type |
KM1024-14PL /42PL head |
Print head controls |
Print head temperature and voltage are software adjustable |
Ink Characteristics |
UV Curing ink |
Ink Reservoir |
Refillable on the fly while printing/1000ml |
RIP software |
Photoprint 10/Onyx/ Caldera |
Color Management |
ICC based color, adjustment curves, density adjustment |
Drying system |
Imported UV lamp |
File format |
TIFF, JPEG, Postscript3, EPS and PDF |
Power supply |
50/60Hz 220V(20%)>20A |
Operation environment |
Temperature 20°C to 28°C degrees |
Humidity |
40% to 60% |
Product Model |
Docan M10 |
Printing Size |
2.05*3.20m |
Media thickness |
1-100mm |
Nozzle Number |
4/5/6/7/8/10/12/14pcs |
|
Resolution |
360dpi*360dpi 360dpi*720dpi |
720dpi*360dpi 720dpi*720dpi | |
720dpi*1440dpi 1440dpi*1440dpi | |
|
Printing speed |
In draft mode up than 60sq.m/h (8 heads) |
In standard mode up than 38 sq.m/h ( 8 heads) | |
In high resolution mode up than 24 sq.m/h (8 heads) | |
Colors |
4 colors(C M Y K) or 6 colors(C M Y K Lc Lm). White & varnish can be optional |
Outdoor life |
3years(By Docan ink), Indoor 10 years |
Loating Mode |
Restro/servo |
Dimensions |
4.8*3.93*1.38m |
Packing |
Inner: plastic bubble film sealed anti rain & rust, outside: solid wooden carton packing |
Weight |
2160kg |
