Specifications
1. resolution to 1440dpi2. Aluminium hardening oxidation vacuum adsorption platform.
3. KM1024 -14pl
4. fast speed
UV flatbed printer, flatbed printer, high quality UV printer
Specifications
M8 model
printed material: wood board, bamboo, ceramic, acryl sheet, etc.
with CE awarded
16 heads automatic printer
Specification
1) UV Inkjet Flatbed Printer
2) CE Certificate
3) 360*360dpi-1440*1440dpi
4) Konica Minolta print head
5) C,M,Y,K or C,M,Y,K,LC,LM + White
Perfect quality along with competitive price
Since we are a few manufacturers of UV flatbed printer in China with many years production experience, we can provide the printer with excellent performance & direct price. You will enjoy our one-stop survice.
Higher speed plus higher resolution
Konica printhead with 1024-14PL nozzle is used to support you with high speed printing and higher resolution(Max resolution can be up to 1440dpi*1440dpi
More application
Application areas includs:Decoration industry, glass industry;Sign industry;Exhibition industry;Leather textile printing industry, etc.
Printed materials could be:Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board & flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, and so on.
Equipment model |
M8 |
Print technology |
Drop-on-demand piezo electric |
Print head type |
KMHB1024-14PL |
Print head controls |
Print head temperature and voltage are software adjustable |
Ink Characteristics |
UV Curing ink |
Ink Reservoir |
Refillable on the fly while printing/1000ml |
RIP software |
Photoprint 10 |
Color Management |
ICC based color, adjustment curves, density adjustment |
Drying system |
UV lamp |
File format |
TIFF, JPEG, Postscript3 EPS and PDF |
Power supply |
50/60Hz 220V(20%)>20A |
Operation environment |
Temperature 20°C to 28°C degrees |
Humidity |
40% to 60% |
Product Model |
Docan UV M8 |
Printing Size |
2.44*1.8m |
Media thickness |
1-80mm |
Nozzle Number |
4/5/6/7/8/10/16pcs |
|
Resolution |
360dpi*360dpi 360dpi*720dpi |
720dpi*360dpi 720dpi*720dpi | |
720dpi*1440dpi 1440dpi*1440dpi | |
|
Printing speed |
In draft mode up than 34 sq.m/h ( single 4 head) |
In standard mode up than 20 sq.m/h ( single 4 head) | |
|
In high resolution mode up than 17 sq.m/h ( single 4 head) In super resolution mode up than 12 sq.m/h ( single 4 head) | |
Colors |
4 colors(C M Y K) or 6 colors(C M Y K Lc Lm). White & varnish can be optional |
Outdoor life |
3 years(use Docan ink) |
Loating Mode |
Restro/servo |
Dimensions |
M8(4.63*2.48*1.47m) |
Packing |
Inner: plastic bubble film sealed anti rain & rust, outside: solid wooden carton packing |
Weight |
1870kg |
