Help CenterDocan UV Inkjet Printer M8 in Fast Speed and Hig Resolution
Related Products
-
UV Flatbed Printer M8 With Konica Minolta 1024 Print HeadsUS$ 50,000 - 100,000MOQ: 1 Set -
Docan UV Flatbed Printer In Fast Speed And High ResolutionUS$ 50,000 - 100,000MOQ: 1 Set
-
Digital UV Flatbed Printer In Large Printing SizeUS$ 50,000 - 100,000MOQ: 1 Piece
-
UV Flatbed Printer Docan M8 (Konica M HB1024 Head)US$ 50,000 - 100,000MOQ: 1 Set
-
UV Flatbed Printer M8 in High ConfigurationNegotiableMOQ: 1 Set
Specifications
uv inkjet printer1. high quality, fast printing speed
2. KMHB1024head
3. can print on rigid and flexible materials
4. CE ce
Model: M8
Print technology : drop on demand piezo electric
Print head : KMHB1024
Print head control: the temperature and voltage are software adjustable.
Ink characteristic: UV curing ink
Ink reservoir: ink supply continuously/ 1000ml
Drying system: UV lamb
Color management: ICC-based color. curves and density adjustment.
File format: Tiff, Jpeg, Postscript 3, Eps and Pdf.
Power supply: 50/60HZ, 220V(10%)>20A
Operation environment: Temperature : 20-28 degree. Humidity: 40% to 60%
Printing size: 2.44*1.65m
Maximum media thickness : 8 cm
Numbers of print head: 4/5/6/7/8/10/16 pcs
Resolution: 360dpi*360dpi to 1440dpi*1440dpi.
Printing speed: draft mode: up than 98 sq.m/h (8 heads)
standard mode: up than 52 sq.m/h
high resolution mode: up than 42 sq.m/h
super resolution mode: up than 32 sq.m/h
Color: 4 colors (C M Y K) OR 6 colors (C M Y K LC LM), white ink and varnish ink can be optional.
Outdoor life: 2 years or more.
Loating mode: Resto/ Servo
Dimensions: 4.63*2.48*1.47m
Package: Iniside: sealed plastic bubble film anti-rain & rust. Outside: export-standard solid wooden carton box.
Weight: 1870kg.
Equipment model |
M8 |
Print technology |
Drop-on-demand piezo electric |
Print head type |
KMHB1024-14PL |
Print head controls |
Print head temperature and voltage are software adjustable |
Ink Characteristics |
UV Curing ink |
Ink Reservoir |
Refillable on the fly while printing/1000ml |
RIP software |
Photoprint 10/ Onyx/ Caldera |
Color Management |
ICC based color, adjustment curves, density adjustment |
Drying system |
UV lamp |
File format |
TIFF, JPEG, Postscript3 EPS and PDF |
Power supply |
50/60Hz 220V(20%)>20A |
Operation environment |
Temperature 20°C to 28°C degrees |
Humidity |
40% to 60% |
Product Model |
Docan UV M8 |
Printing Size |
2.44*1.8m |
Media thickness |
1mm -----100mm |
Nozzle Number |
4/5/6/7/8/10/16pcs |
|
Resolution |
360dpi*360dpi 360dpi*720dpi |
720dpi*360dpi 720dpi*720dpi | |
720dpi*1440dpi 1440dpi*1440dpi | |
|
Printing speed |
In draft mode up than 58 sq.m/h (8 heads) |
In standard mode up than 42 sq.m/h (8 heads) | |
In high resolution mode up than 34 sq.m/h (8 heads) | |
In super resolution mode up than 26 sq.m/h ( 8 heads) | |
Colors |
4 colors(C M Y K) or 6 colors(C M Y K Lc Lm). White & varnish can be optional |
Outdoor life |
2 years(use Docan ink) |
Loating Mode |
Restro/servo |
Dimensions |
M8(4.63*2.48*1.47m) |
Packing |
Inner: plastic bubble film sealed anti rain & rust, outside: solid wooden carton packing |
Weight |
1870kg |
