Specifications
UV printer1. high quality, fast printing speed
2. Konica KMHB1024head
3. print on flatbed materials
UV printer
we are professional manufacturer of UV flatbed printers.
We produce different models with different printing size.
|
General Info |
Model |
M8 |
Print technology |
Drop-on-demand Piezo Electric |
|
Printhead type |
JAPAN KM-1024-14PL |
|
Printhead No. |
4/5/6/7/8/10/12 pcs |
|
Printhead controls |
Print head temperature & voltage are adjustable by software |
|
Printing size |
2.44m x 1.50m |
|
Ink type |
UV curing ink |
|
Ink Reservoir |
Refillable on the fly while printing/1000ml |
|
Loating mode |
Resto/Servo |
|
RIP software |
Photoprint 10 or Caldera/Onyx |
|
Drying system |
UV lamp |
|
File format |
TIFF, JPEG, Postscript 3, EPS and PDF |
|
Resolution |
360 dpi x 360 dpi 360 dpi x 720 dpi |
|
720 dpi x 360 dpi 720 dpi x 720 dpi | ||
720 dpi x 1440 dpi 1440 dpi x 1440 dpi | ||
Printing Speed |
In draft mode up than 46 sq.m ( 4 heads ) |
|
In standard mode up than 26 sq.m ( 4 heads ) | ||
In high resolution mode up than 21sq.m ( 4 heads ) | ||
Ink |
Ink type |
UV curing ink |
Ink color |
4 colors (C, M, Y, K) - 7colors (C, M, Y, K, LC, LM + W) |
|
Printing Assistant System |
Printing media (1-80mm thick) |
Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board & flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, etc. |
Heating system |
Standard (Front heater, Rear heater, Fan) |
|
Color retains |
Outdoor 3 years, indoor 7 years |
|
Color management |
ICC based color, adjustment curves, density adjustment |
|
Printer Info |
Power supply |
AC220V 50/60HZ (10%) 20A |
Working conditions |
Temperature 20-28 degrees, Humidity 40% - 60% |
|
Dimensions |
4630*2480*1470mm |
|
Weight |
1870kgs |
|
Packing |
Outside packing : Packed by solid wooden carton |
|
Inner packing: sealed with anti-rain & rust plastic bubble film | ||
