HFE100 Digital Portable Ferrite meter, Ferrite testing machine
1. Preface
In the chemical industry the stress-bearing members of containers,pipes,reactor vessels and other plant are usually made of austenitic steel or duplex steel or cladding of austenitic chromium-nickel steel.The residual ferrite content must be within a specific range compatible with the mechanical strength requirements or the item concerned.
The HFE100 was developed to facilitate accurate ferrite content measurements On welded seams and cladding items. It gives results that match for the standards of GB/T1954-2008,ISO 8249 and ANSI/AWS A4.2.
2. Feature
LC-display,
Two display modes (SAVE and FREE).
Two units — Fe% and FN (WRC number).
Statistics display together with measurements.
Built-in Rs-232 interface for printer(Option if need)
3. Technical data
The meter is mainly used for the determination of the ferrite content
of welded austenitic steel or Duplex or cladding of austenitic
chromium-nickel steel weld.
Range 0.1~80%Fe , ( 0.1~110)WRC-number
Precision ±2%(raneg0.1~30%Fe), ±3%(raneg30~80% Fe)
Operating temperature 5 ~ 40°C
Batteries 9v 6F22
Size: LX WX H 175X100X38mm
Accessories Carrying-case , Operating Manual
