Specifications
Air Cooled Condenser-With Fan Motor
-CE Certificate,Copper Tube&AL Fin
-Condensing Unit Parts
-Cold Room Refrigeration
Air Cooled Condenser with Fan Motor for Condensing Unit Introduction
Air cooled condenser is a kind of cooling devices by utilizing air which connected with Freon refrigeration equipments. Now we produce FN, FNS type and FNV type air cooled condenser, Air side outlet for FN&FNS type and Air top outlet for FNV type.
Features
1. The outcovering is made of high-quality steel plate with sprayed surface to ensure corrosion resistance, beautiful appearance;
2. Coil adopted staggered permutation, and tighten to fit with Aluminum sheet to ensure high efficiency heat exchange;
3. Units adopted 2.8MPa air tightness test and system sewage discharge treatment;
4. Application for R22,R134a,R404a,R407C etc. Refrigerant;
5. FNS condenser utilized large air volume and low speed internal motors with low noise,beautiful appearance; Application for refrigerant equipments which demand high requirements of noise;
6. FNV condenser has the features of large windward side, high quality heat exchange; external rotor motors used.
Air Cooled Condenser Models Specifications
FN S ----- 80 A
FN: Condenser Products Code
S: Type: S(Low Noise Type); V(Air Top Outlet Type); P(Water Spray Type); None(Standard Type)
80:Heat Exchange Area(m2)
A: Model Change Design Code
Technical Data Sheet of Air Cooled Condenser
Air Cooled Condenser with Fan Motor:
Air Cooled Condenser with Fan Motor Production Lines:
