Home > Electrical & Electronics > Antenna > Communication Antenna > Omni Directional Outdoor High Gain 10dBi Fiberglass Gsm Base Station Antenna
Omni Directional Outdoor High Gain 10dBi Fiberglass Gsm Base Station Antenna
US$ 2 - 3
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
SD gsm base station antenna
Model Number:
SDBF890 gsm base station antenna
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen for gsm base station antenna
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
GSM Antenna / CDMA Antenna/ Adhesive Antenna on Window for CarUS$ 0.20 - 0.50MOQ: 1 Piece -
Omni Directional Dual Band in Building Wireless and Gsm Wall Mount Antenna With L BracketUS$ 1 - 2MOQ: 1 Piece
-
900-1800MHZ Outdoor GSM Modem With External AntennaUS$ 1 - 2MOQ: 1 Piece
-
Omni Directional Quad-band GSM Antenna With Mini Magnetic Mount and Mini Whip /gsm Modem With External AntennaUS$ 1 - 2MOQ: 1 Piece
-
800/1900 or 900/1800Mhz CDMA/GSM Magnetic Mount Car Antenna With RG58U CableUS$ 2.00 - 4.00MOQ: 1 Piece
Place of Origin
Fujian, China
Brand Name
SD gsm base station antenna
Model Number
SDBF890 gsm base station antenna
Omni directional outdoor high gain 10dBi fiberglass gsm base station antenna
Electrical specifications | |
Frequency Range(MHz) |
824-896 or 890-960 |
Polarization |
Vertical |
Impedance |
50 Ohm |
Gain (dBi) |
10 |
Radiation |
Omni |
Horizontal Beam Width |
360º |
Vertical Beam Width |
12º |
VSWR |
≤1.5 |
Maximum input power (W) |
100 |
Lighting Protection |
Direct Ground |
Mechanical specifications | |
Connector |
SO-239 or customization
|
Connector position |
Bottom |
Length |
2200±20 mm
|
Packing weight (kg) |
2.5 |
Radiating Material |
Cu |
Radome Material |
Fiberglass |
Color |
White |
Operating temperature (℃)
|
-50~70
|
Material of Hardware-supplied |
Metals |
Mounting hardware (mm) |
Ø40-50mm |
other similargsm base station antenna products:
| MOQ | 1 piece (small or trial order), 100pcs for bulk order |
| Packaging | ShengDa Standard Package |
| Loading Port | XIAMEN for gsm base station antenna |
| Delivery Date | Within 3 days after payment confirmed |
| Express Delivery | DHL/UPS/FEDEX/EMS/TNT |
| Terms of Payment | T/T, Western Union, Paypal |
Our Services
1.17 years experience .Shengda communication Ltd.,which mainly produce mobile antenna, Hand held antenna and marine antenna, base station antenna,yagi antenna products.
2. Our sales will reply your inquiry in 24 working hours.
3. Customized design is available, OEM are welcomed.
4. Excellent after-sales service.
