Help CenterScrew Compressor Air Cooled Water Chiller With High Efficiency and Top Quality
Related Products
-
High Quality High Efficiency and Environmental Box Type Protection Air Cooled Water ChillerNegotiableMOQ: 1 Unit -
Most Energy Saving Air Cooled Water Chiller, 87-1000kw; CE CertificateNegotiableMOQ: 1 Set
-
8kw-120kw,Durable Energy Saving and Environmental Friendly Scroll Compressor Air Cooled Chiller for Air ConditioningNegotiableMOQ: 1 Unit
-
D Series, Air Cooler/Evaporator For Refrigeration Cold RoomNegotiableMOQ: 1 Unit
-
Central Air Conditioner Screw Compressor Air Cooled Water Chiller With High Quatity and Competitive PriceUS$ 1,358 - 98,996MOQ: 1 Unit
Specifications
Air Cooled Water Chiller-Energy Saving
-High Efficiency & Good Quatity
-CE,CRAA ISO
-High Performance
TOP Quality High Efficiency Air Cooled Screw Chiller for Cooling Only in Building,Hotel,Villa,Restaurant,etc,No Cooling Tower Needed with Bitzer,Refcomp,Hanbell Screw Compressor
Main Parts of Screw Air Cooled Water Chiller
1.Fin type air-cooled condenser: Fin type air-cooled condenser adopts imported high purely, seamless screw thread copper and special aluminum fin after mechanical expanding joint closely. It ensures fin type condenser work in best efficiency Fin type air-cooled condenser adopts imported high purely, seamless screw thread copper and special aluminum fin after mechanical expanding joint closely. It ensures fin type condenser work in best efficiency;
2. Tube in tube(Shell and Tube) type evaporator:
1) It is tube in tube structure with new developed fire-proof and water-proof material as heat preservation. The
water-side working pressure may reach to 2.0 MPa.
2) There is PVC engineering plastic breakwater inside of evaporator with strong anti-corrosion ability. Chilling
water circuitous goes up and down to increase tumble effect, and heat exchange ability.
3) Adopt new technology DAC weave interior screw threat, high efficient heat exchange tube to ensure good
cooling characters.
3. Semi-hermetic screw compressor:
The unit uses imported semi-hermetic screw type compressor. Comparing piston type compressor, the
semi-hermetic screw type compressor has following advantages:
1) Less accessories (Approximately 1/3 of piston compressor). The unit structure is simply and long service life).
2) The unit EER ≥3.1W/W;
3) Screw type compressor may adjust energy in range 25% - 100%.
4.Four-way valve:
Air-cooled water chiller adopts PE four-way valve from Unit State, so that solves reversing and system consume great problem exist in other same kind of products.
5.Expension valve: Thermal expension valve
Introduction:
The LTLF series screw compressor chillers is the leading products manufactured by LVTE AIR CONDITIONING Company;
The products can provide 7-20°C chilled water, cooling capacity ranging from 50KW to 4000KW;
Feature high EER, low noise level, easy operation and maintenance; with more than 40 kinds of models;
This series of products is applicable to the industrial process cooling and air conditioning systems.
Features:
1.Twin screw compressors of world famous brand is adopted, with high efficiency, low noise level, less wearing and long operation time.
2. The unit is of high performance as they are made of the condensers and evaporators of grooved copper pipes, and high quality components, by specialized process.
3. The unit is easy to operate, and friendly interfaced, as they adopt leading brand PLC, 64K color touch screen and other control elements.
4. The energy saving for Multi-capacity regulation, resulted in cost cut down for operation and maintenance.
5. Imaged system operation chart, showing the temperature of water in/out, the energy level of compressor run, on/off button, run time, alarm etc. And the remote turn on/off function is available. PC remote control is optional.
Certificate of Products
