Air Cooled Water Chiller

Air Cooled Water Chiller thumbnail-1
Air Cooled Water Chiller photo-1
US$ 589 - 7,869 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
LYTTE or OEM Service
Model Number:
LT-Air Cooled Water Chiller
Contact Supplier Request Quote Chat Now
Shandong Lvte Air Conditioning System Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name LYTTE or OEM Service
Model Number LT-Air Cooled Water Chiller
Type Other, Air Cooled Water Chiller

Specifications

Air Cooled Water Chiller
-Air Cooled Chiller
-Air to Water Chiller
-Cooling capacity 8-120KW
-Air Cooled Water Chiller

Air Cooled Water Chiller

INTRODUCTION:

1.With scroll, or recipocating compressor of high quality, high efficient heat exchangers, excellent system design, by excellent process, the chillers is of suffient capacity and efficiency.

2.The chillers will work stably for long time period as they are produced by excllent process, composed of reliable control components and professional control procedure.

3.Complete safety protection:

a.High&low pressure protection, pressure safety value protection;

b.Overload protection to the compressor;

c.Power supply protect for phase lack, counter phase, voltage too high and voltage deficient;

d.Water system protection for freezing breaking, water lack etc.

Model Details:

1.Colling Standard Condition:Chilled water in/out 12/7°C;Ambient Temperature 35°C;

2.Suitable chilled water temperature: 9-25°C;

3.Power supply: 3P-380V-50HZ;with voltage allowance ±10%,voltage dif between the phase lines±2%;

MODEL LT- 03AS 05AS 08AS 10AS 12AS 15AS 20AD 25AD 30AD 40AD
Cooling
Capacity		 KW 8.3 13.7 22.1 29.5 34 44.1 59 68 88.2 120
103kcal/hr 7.1 11.8 19 25.4 29.2 37.9 50.7 58.5 75.9 103
Power(kW) 3.1 5 7.4 9.7 11.9 15.3 19.4 23.7 30.6 40.5
Current(A) 5.7 9.7 14.3 18.2 22.1 28.8 36.3 44.1 57.6 64.2
Compressor Quty(PCS) 1 1 1 1 1 1 2 2 2 2
Power(kW)  2.55 3.96 6.11 8.06 9.9 12.4 16.1 19.8 24.8 34.1
Current(A) 4.39 7.69 11.4 14.9 18.3 22.7 29.7 36.5 45.4 49.6
Refrigerant Type R22
Control Thermal expension valve
Fan Power(KW) 0.2 0.45 0.5 0.9 1.2 1.4 1.7 2.2 3.12 4.2
Current(A) 0.6 0.9 1.4 1.8 2.3 2.9 5.4 7.6 9.6 10
Water Pump Type Centrifugal pump
 Power(KW) 0.37 0.55 0.75 0.75 0.75 1.5 1.5 1.5 2.2 2.2
Current(A) 0.75 1.1 1.5 1.5 1.5 3.2 3.2 3.2 4.6 4.6
Pressure Head
(mHo2)		 15 20 22 20 17 25 24 18 22 22
Condenser Type Copper tupe and al fin
Evaporator water pipe
connection(mm)		 DN25 DN40 DN50 DN65
Water flow
(L/min)		 23.7 39.3 63.4 84.6 97.5 126 169.1 194.9 252.8 344
Water Tank Volume(L) 65 75 140 140 150 250 325 325 370 400
Fill,discharge,
overflow port		 DN20
Overall Size Length mm 1060 1060 1520 1620 1720 1810 2020 2270 2470 2670
Width mm 740 740 850 850 850 930 1010 1150 1150 1240
Hight mm 1340 1450 1550 1600 1600 1730 1930 1930 2080 2220
 Weight KG 220 236 320 372 435 610 750 850 950 1050

Air Cooled Water ChillerAir Cooled Water Chiller
