Specifications
Air Cooled Water Chiller1.Scroll Compressor Copeland
2.For Air Conditioning ir Industry
3.R134a,R407C,R22 Available
4.CE
Air Cooled Water Chiller
Two Kinds of Models: Air Cooled Water Chiller/Air to Water Chiller
1. Cooling Condition: Chilled Water In/Out 12°C/7°C;Ambient 35°C
Models: LTWF03AS-40AD Cooling Capacity: 8KW-120KW
2.Cooling Condition: Chilled Glycol in/out -1/-5°C; ambient 35°C
Models: LTWF03ASL-40ADL Cooling Capacity: 4.7KW-61.6KW
INTRODUCTION:
1.With scroll, or recipocating compressor of high quality, high efficient heat exchangers, excellent system design, by excellent process, the chillers is of suffient capacity and efficiency.
2.The chillers will work stably for long time period as they are produced by excllent process, composed of reliable control components and professional control procedure.
3.Complete safety protection:
a.High&low pressure protection, pressure safety value protection;
b.Overload protection to the compressor;
c.Power supply protect for phase lack, counter phase, voltage too high and voltage deficient;
d.Water system protection for freezing breaking, water lack etc.
FEATURE
Ready to work only after connected to chilled water system;
A stainless steel water vessel,a low noise pump have been fixed inside the chiller;
With energy saving fan of large air flow and low noise;
The chillers of capacity below 50KW is movable by wheels with them;
The chillers of capacity over 50KW are double refrigeration system design that is good to reduce the frequent start and stop for load change. The chillers can run even 1 system is in trouble.
Strict test and inspection has been made before the chillers are delivered.
Model Specifications:
1. Cooling Condition: Chilled Water In/Out 12°C/7°C;Ambient 35°C
Models: LT03AS-40AD Cooling Capacity: 8KW-120KW
| MODEL LTWF- | 03AS | 05AS | 08AS | 10AS | 12AS | 15AS | 20AD | 25AD | 30AD | 40AD | |
| Cooling Capacity | KW | 8.3 | 13.7 | 22.1 | 29.5 | 34 | 44.1 | 59 | 68 | 88.2 | 120 |
| 103kcal/hr | 7.1 | 11.8 | 19 | 25.4 | 29.2 | 37.9 | 50.7 | 58.5 | 75.9 | 103 | |
2. Cooling Condition: Chilled Glycol in/out -1/-5°C; ambient 35°C
Models: LT03ASL-40ADL Cooling Capacity: 4.7KW-61.6KW
| MODEL LTWF- | 03ASL | 05ASL | 08ASL | 10ASL | 12ASL | 15ASL | 20ADL | 25ADL | 30ADL | 40ADL | |
| Cooling Capacity |
KW | 4.7 | 7.5 | 13.7 | 16 | 18 | 22.7 | 32 | 36 | 45.4 | 61.6 |
| 103kcal/hr | 4 | 6.5 | 11.8 | 13.8 | 15.5 | 19.5 | 27.5 | 31 | 39 | 53 | |
