Specifications
Sunflower seed oil refinery equipment1.High efficient & long time running
2.Excellent performance
3.Easy operation
Sunflowerseed oil refinery equipment
1. High efficient & long time running
2. Excellent performance
3. Easy operation
Technical characters:
It adopts advanced plane turning screen and stone separator to clean oil plant,and then crash,flake,cook,mill and filter them. It has advanced techniques and high automatization level.
Main Refining Processes for sunflowerseed oil refinery equipment:
De-mixed, degumming, dehydration, deacidification, decolorzation, dewaxing and deodorization.
1. Degumming :Usded to neutrilizing ,and water washing,to rid off the acid .
2. Deodorization:Used to rid off the fetid smell/odour of oil by steam understand of high temperature.
3. Soap feet vessel:Used to refine the oil sediment from oil refiner,to get some oil from oil sediment .
4. Hot & Alkali water tank:Used to produce hot water heated by the steams ,also alkali water from the alkali dis-voling tank,for adding into the oil refiner.
5. Alkali dis-voling tank :Used to produce the alkali water .
6. Steam separator:Separating the steam to oil refiner,de-colorer,deodorizer,hot water tank,etc.
7. Decoloring vessel:Used to rid off the color of the oil
8. Clay tank:Store the medication decolored for the clay tank.
9. Transfer hot oil furance:Contact to the deodorizer part , producing high temperature (280 degrees orso) for deodorization.
10. Gear pump:Pump oil into kinds of vessel and tank.
12.Water pump:Pump cool water into water tank.
13. Transfer hot oil pump:Pump hot oil into transfer oil furance.
14. Cooling water tower:Cool water for cooling oil ,recycling using.
15. Dewaxing /winterization / fractional
Steam consumption |
700KG/T oil |
Electric consumption |
28Kwh/T oil |
Water (soften water) |
150Kg/T oil |
Phosphoric acid |
2~3 kg/T oil |
Alkali |
acid valuex1-3kg/T oil |
Circulating water cooling water yield |
150M3/H |
Bleaching earth consumption |
3-5Kg/T oil |
Waste bleaching earth oil content |
≤25~35% |
Refining losses |
acid valuex1.2 (chemical refining) acid valuex 0.6 (physics refining) |
Bleaching losses |
the quantity of bleaching earth×0.25% |
Deodorization loss consumption |
≤0.5%≤0.5% |
Refining rate |
1-refining consumption |
