50-500TPD Sunflower oil refining machine,Sunflower oil refinery equipment,
sunflower oil refining manufacture
Part-1: 50-500TPD Sunflower oil refining machine,Sunflower oil refinery equipment,sunflower oil refining manufacture Process:
1) The main function of decoloring process is to remove oil pigment, residual soap grain and metal ions.
2) Under negative pressure, the mechanical mixing method combined with steam mixing will improve the decoloring effect.
3) The degummed oil firstly enters into the heater to be heated to the appropriate temperature (110°C), and then goes to the bleaching earth mixing tank.
4) The bleaching earth is delivered from the low bleaching box to the temporary tank by wind.
5) The bleaching earth is added by automatic metering and is interlockingly controlled with the oil.
6) The oil mixed with the bleaching earth overflows into the continuous decolorizer, which is stirred by non-powered steam.
7) The decolored oil enters into the two alternate leaf filters to be filtered.
8) Then the filtered oil enters the decolored oil storage tank through the security filter.
9) The decolored oil storage tank is designed as the vacuum tank with the nozzle inside, so as to prevent the decolored oil contacting with the air and influencing its peroxide value and color reversion.
Part-2: 50-500TPD Sunflower oil refining machine,Sunflower oil refinery equipment,sunflower oil refining manufacture features:
1) For the continuous refining technology, our company has absorbed the advanced technology at home and abroad.
2) By combining several years' practical experience, adopting a kind of unique deguming technology, extending the phosphoric acid and oil reaction time and adding specific additives, our equipment can remove phospholipids in oil to the maximum.
3) The new carclazyte automatic quantitative system can produce more reliable oil of good quality, with less investment for the full vacuum closed refining technology.
4) We can design the optimum refining scheme according to different oils and different requirements for products.
Part-3: 50-500TPD Sunflower oil refining machine,Sunflower oil refinery equipment,sunflower oil refining manufacture Technical parameters:
Steam consumption |
450KG/T oil |
Electric consumption |
28Kwh/T oil |
Phosphoric acid |
2~3 kg/T oil |
Circulating water cooling water yield |
150m³/H |
Bleaching earth consumption |
5~50Kg/T oil |
Waste bleaching earth oil content |
<35% |
Deodorization loss consumption |
≤0.5% |
Part-4: Certification
Part-5: Customer and delivery
