Specifications
1.ISO/IEC 11801,ANSI/TIA/EIA-568BUL &ISO900 1&PASS FLUKE TEST
2.OEM service
3.lan cable,telephone cable,coaxial cable
LAN CABLE patch cord cable
Specification:
BC: Bare Copper CCS: Copper Clad Steel
CCA: Copper Clad Aluminium P: Pairs
1) 4P*7*0.2mm BC/CCA/CCS Conductor+1.02mm PE Insulation+ 6.2mm PVC Jacket
2) Customers' specifications are wellcomed.
Note:
1)Rated Temperature: 60º C, 75º C
2) Center Conductor: BC, CCS, CCA.
3) Colour-coated PE insulation
4) Flammadbility Grade: CMX, CM, MP, CMG, MPG, CMR, MPR
5) PVC or LSZH jacket
Conductor:
Material:Bare copper
Number of pairs:4pairs
AWG:24awg
Conductor diameter:7*0.2mm
Insulation:
Material:HDPE and FRPE
Diameter:1,02±0.005mm
Average thickness:0.212mm
Minimum point thikness:0.2095mm
Rip cord:optional
Sheath:
Material:PVC,PE or LSOH
Nominal diameter:6.2±0.2mm
Average thickness:0.50mm
Operating temperature:-20 to 75°C
Minimum bend radius (install):(8*OD)
Flame test:CMX,CM,and IEC60332-1
Application:
10 Base-T
100 Base-TX
100VG-AnyLan
1000 Base-T(Gigabit Ethernet)
155 Mbps ATM
622 Mbps ATM
Reference standard:TIA/EIA568B and IEC/ISO11801
Products Photos:
Certificate:
We have pass the IS09001, CCC, Rohs, CE, and UL, in order to meet your market requirement.
Factory and Production line
We use the bue advance production equipment for LAN CABLE,TELEPHONE CABLE, and COAXIAL CABLE, ensure the high performance in your project and system.
Exhibition Trade Show
We attend to 3-5 Fairs in Hongkong, Guangzhou, and aboard, to meet with the old customer, also show our company to the future new customers.
More types of Cables we do
We also produce these cables for more than 20 years, RG6,RG11,RG59 COAXIAL CABLE, TELEPHONE CABLE, ALARM CABLE.MICROPHONE CABLE etc.
Hangzhou Lin`an Dongsheng Cable Co.,Ltd, was established in 1991,located at the foot of the Tianmu Mountain in Lin`an city, is 28km away from Hangzhou City, which is close to Shanghai port and Ningbo port with facilitated transportation
As a professional cable manufacturer in china,We specialized in producing of Coaxial Cable RG59,RG6,RG11 CATV and CCTV, Lan Cable Cat3,Cat5e,CAT6 UTP/FTP /SFTP for Indoor and Outdoor,Telephone Cable,Combined Cable,and cable accessories etc. We are covering 1,6000 square meters,including standard workshops and warehouse,to ensure your goods in goods production condition.
Meanwhile,Our company has obtained ISO9001,also our products has passed CE,RoHS ,UL certificate, which is Promise high quality cable .
Dongsheng Cable products have been exported to Southeast Asia ,Middle East, European,South America,USA and gain good
reputation.We will meet client requirements with top quality,advanced technology, perfect management and excellent service
