Specifications
1) High quality 75 ohm RG59 BNC Connector2) Since 1991 year
3) For catv cctv system
4) RG6 RG11RG174 LMR400 QR500 RG213 RG58
High quality 75 ohm RG59 BNC Connector / RG59 RF connector / RG59 connector
75 ohm RG59 BNC Connector
BNC RF connector male for RG6 RG11 RG59
| Key Performance | ||||||
| Temperature range | -65~+165 | Insulation resistance | ≥5000MΩ | |||
| Characteristic impedance | 50Ω/75Ω | Dielectric Withstanding voltage | 750V(r ms) | |||
| Frequency range | 0~4GHz(50Ω) | VSWR | ≤1.30 | |||
| 0~2GHz(75Ω) | ||||||
| Voltage rating | 500V(r ms) | Disengage force |
≥0.6N |
|||
| Contact resistance | Center conductor |
≤1.5mΩ |
Durability | 500 Cycles | ||
| Outer conductor |
≤1mΩ |
|||||
| Material And Plating | ||||||
| Body | Brass , nickel plated | |||||
| Male center contacts | Brass , gold plated | |||||
| Female center contacts | Beryllium copper or phosphor bronze , gold plated | |||||
| Insulators | PTFE | |||||
| Gaskets | Beryllium copper , gold plated | |||||
| Crimp ferrules | Copper alloy , gold or nickel plated | |||||
Product Packing :
- 100Pcs/Pack
- 1.2KG /Bag
- 3000Pcs/Carton
Supply 50ohm and 75 ohm Coaxial Cable Connector
50 ohm Cable Connector : RG174 RG58 RG8 RG213 RG214 LMR400 LMR300 ect.
75 ohm Cable Connector : RG6 RG59 RG11 QR540 QR500 QR412 KX6 KX8 CT100 19VATC
RG6 Coaxial Cable Product Specification:
Coaxial Cable-CATV/MATV |
TYPE: |
RG6BV-60% |
|||
|
Construction | |||||
Item |
Material |
Diameter(mm) |
|||
Center Conductor |
Copper Clad Steel/Bare Copper |
1.02 |
|||
Dielectric |
Foam PE |
4.57 |
|||
1st Shield |
Bonded Aluminum Foil |
4.75 |
|||
2nd Shield |
Aluminum Wire Braiding 60%~95% |
4×16×0.16 or 112*0.16 |
|||
Jacket |
PVC |
6.91 |
|||
Electrical Charateristics |
|
|
|||
Impedance(Ω) |
75±3 |
||||
Capacitance(pF/m) |
52±2 |
||||
Velocity of Propagation(%) |
85.0 |
||||
Shielding Effectiveness |
|
||||
5-1000MHZ(dB) |
≥80% |
||||
Return Loss |
|
||||
5-1000MHZ(dB) |
≥22 |
||||
1000-2000MHZ(dB) |
≥20 |
||||
|
|
||||
Attenuation @68°F.(20 ℃ ) | |||||
@Frequency(Mhz) |
Max Attenuation(dB/100ft) |
Max Attenuation(dB/100m) |
|||
5 |
0.58 |
1.90 |
|||
55 |
1.60 |
5.25 |
|||
187 |
2.85 |
9.35 |
|||
211 |
3.05 |
10.00 |
|||
400 |
4.15 |
13.61 |
|||
500 |
4.66 |
15.29 |
|||
750 |
5.65 |
18.54 |
|||
865 |
6.10 |
20.01 |
|||
1000 |
6.55 |
21.49 |
|||
1500 |
8.20 |
26.80 |
|||
1800 |
8.80 |
28.90 |
|||
2200 |
9.80 |
32.20 |
|||
3000 |
11.50 |
37.60 |
|||
Coaxial Cable RG6 RG59 RG11
1) 75 ohm cable coaxial rg59 67% or 95%
0.81mm CCS /CU+3.66mm FPE+Bonded Al Foil+67% 0r 95% mm Al +6.0mmPVC
Packing: 100m/Roll, 200m/Roll, 305m/Wooden drum, 500m/wooden drum
2) 75 ohm Cabo Siamese Cable RF 4mm+2*26AWG
7*0.18 mm CCA+2.4±0.10 mm SPE+16*4*0.12mm80% CCA+4.10mmPVC+2*26AWG
Packing: 100m/Roll, 300m/Plastic reel
3) 75 ohm cable coaxial rg6 95% messenger cable
1.02mmCCS /CU+4.57mmFPE+Bonded Al Foil+ 67% 0r 95% mm Al +6.9mmPVC+1.3 Messenger steel
Packing: 100m/Roll, 200m/Roll, 305m/Wooden drum, 500m/wooden drum
4) 75 ohm cable coaxial rg11 90% messenger wire
1.63mmCCS/ CU+7.11mmFPE+Bonded Al Foil+128*0.15mmAl+10.03mmPVC+1.83mm Messenger Steel
