high quality and large capacity way feeder for ball mill
WHAT WE CAN DO FOR YOU:
The scope of work
- Investigation, characterization and evaluation of raw materials and products
- Consulting in plant modifications, techniques and improvements to reach the market requirements
- Development of new processing technologies and techniques including tests of mechanical, thermical and chemical processes
- Project management for plant modifications with commissioning and training of customer’s staff
- Design and project planning of plants including the engineering and specifications for local supplies
- Consultancy in final product applications and assistance for marketing international
Project Step
Step 1: Feasibility study
In this phase, the effort is to get a rough overview of budget, design, time schedule and economic efficiency of the project. Hereby is given a first and crucial opportunity of a project decision according to the terms of profitability and feasibility.
Step 2: Project preparation
This phase includes process and process steps definition (important for interfaces), pre layout, budget, time schedule, procurement, processing tests, selection of co-operation partners, financing and permitting. Here is given the second opportunity of a project decision.
Step 3: Project realisation
In this phase the project will be realized by us by managing the whole project, comprising the final design, budget, time schedule, interfaces, construction work, etc. up to the start-up in dependence on the terms of contract. Also in this phase, it is important to evaluate the human resources and to hire and train the operational staff.
Our technology group have more than ten years' experience.
Also our after-sales service engineer group also are very experienced on installation, commissioning and text-run.
They also will training customers' workers.
some of customers' reference:
FEATURES
- special design for feed material with high hardness
- Low speed, low abrasion
- best ratio of length and diameter ,no over-grinding
- Low energy consumption, no pollution
- feed at even speed, higher grinding effiency
Scope Of Application
quartz, zircon sand etc.
|
size of ball mill Parameters |
Ø1.8X4.5m |
Ø2.2X4.8m |
Ø2.4X5.0m |
Ø2.6X5.5m |
Ø2.8X6.0m |
Ø3.0X6.5m |
|
motor power kw |
75/90 |
132/160 |
185/200 |
220/250 |
315/355 |
400/450 |
|
D97:45um |
classifier model |
ATP315 |
ATP400 |
ATP500 |
ATP570 |
ATP630 |
ATP750 |
Quartz production t/h |
1.0~1.1 |
1.6~1.8 |
2.5~3 |
3.5~4.0 |
4.0~4.5 |
5.5~6.0 |
|
Zircon sand production t/h |
1.1~1.3 |
1.8~2.0 |
3.0~3.5 |
4.0~4.5 |
4.5~5.0 |
6.0~6.5 |
|
D97:10um |
classifier model |
ATP315 |
ATP400 |
ATP500 |
ATP315/4 |
ATP315/6 |
ATP315/6 |
Quartz production t/h |
0.15~0.2 |
0.3~0.35 |
0.5~0.55 |
0.6~0.7 |
0.8~0.9 |
1.0~1.2 |
|
D50:1.0~1.2um |
classifier model |
ATP315 |
ATP315/3 |
ATP315/3 |
ATP315/4 |
ATP315/6 |
ATP315/6 |
Zircon sand production t/h |
0.1~0.15 |
0.25~0.3 |
0.35~0.4 |
0.4~0.5 |
0.6~0.7 |
0.8~1.0 |
|
Note: 1. the above data is based on feeding size is 40~100mesh.
2. different material from different disctrict has different characteristics, so, the capacity will also
be different accordingly
3. the above data only depends on two traditioanl material with high hardness, if other material,
please contact me freely for consultant
Quality guarantee is for 18 months. During 18 months, if there is any problem or destroy (non-artificial damage), we will repair or change for free. After 18 months, if there is any problem, we will still supply good service, and we will charge cost if parts needed to be changed.
- Flow sheet of the process
- Electrical interlocking sequence
- Dimension drawings for supplied equipment
- Operation manuals
- Technical information and specification for local supply
- Engineering drawings for local supplies
- Technology data and drawings for installation and commissioning
- Spare parts list
