The Introduction sawdust briquette machine :
1.sawdust Briquette machine is the main equipment to make stick solid fuel with such raw materials as tree branch , rice shell , peanut shell ,cotton stalk,etc. not contain any additives .
2.The raw material (size below 3-5mm, moisture contain 8-12%)will be formed into wood briquette under high temperature and pressure.
3.The outlet briquettes has the features of high density, small volume, good flammability, which can take place of fuel wood and coal .
4.The common diameter of sawdust briquettes is 50-80mm. And the shape can be
The main parameter of sawdust briquette machine :
We have several kinds ofsawdust briquette mmachine, the capacity is from 120 kg/h to 450 kg/h; the power also has the different scope; but the moisture content all require in 8-12%, the scope is the optimal range to make briquette.
The detailed information about sawdust briquette machine's model is as below:
Model | Power (kw) | Capacity (t/h) | Material moisture | Weight (t) | Dimension (m) |
GXZBJ50-9 | 11-15 | 0.12-0.22 | 8-12% | 0.55 | 2.2*0.6*1.3 |
GXZBJ50-C | 22 | 0.35-0.42 | 8-12% | 0.75 | 2.7*0.7*1.5 |
GXZBJ60-9 | 15-18.5 | 0.22-0.25 | 8-12% | 0.65 | 2.4*0.7*1.35 |
GXZBJ70-9 | 18.5-22 | 0.28-0.34 | 8-12% | 0.78 | 2.4*0.7*1.4 |
GXZBJ80-9 | 22 | 0.32-0.36 | 8-12% | 0.85 | 2.4*0.75*1.4 |
GXZBJ90-9 | 30 | 0.38-0.45 | 8-12% | 0.98 | 2.6*0.8*1.5 |
Sawdust Briquette machine for Raw material could be:
Maize stalks, soybean stalks, fire wood ,parawood scraps,palm shell,broomcorn stalks, cotton stalks, peanut plants, sunflower stalks, bamboo saw dust,bagasse, wood chips, rice husk, coffee husk,coir pith, jute sticks, groundnut shells, Bamboo,wood, Mustard stalk and cotton stalks etc.
Sawdust Briquette machine for Requirement of the raw material :
1.Size:smaller than 5mm , if the material can not achieve the requirement, it should be crush first.
2.Moisture :8-12%,If raw material has high moisture it should be reduced by Sun drying or using flash drier.
Final products from sawdust briquette machine :
This bio-fuel briquette is 45-80mm in diameter 80mm ,Occurs in the hollow quadrangular or hexagonal clinder or hollow hexagonal with a 15-20mm hole through the body.
- The available shape: square, hexagonal, pentagon, pentagon with edge, hexagon with edge
- The available diameter could be: 50mm,55mm.60mm,65mm.70mm.80mm and so on
- The available length could be :20cm,30cm, 40cm, 50cm
- The feature of the final product : Specific gravity: 1300—1900kg/m Calorific value: 4500—5000kcal/kg
Pre-sale:
1. Suggest to client suitable models of our carbonization furnace, according to the raw material, including its type,
huimidity, final charcoal capacity requirements.
2. Introduce machine's structure and features in detail, explain the price component;
3. answer client concerned questions.
After-sale:
1. Start production as soon as receiving down payment.
2. Send photos of machine in manufacturing and finished photos to client, for your better learn about the machine's
condition.
3. Delivery machine in time, taking photos during loading, so you can "remote monitoring" your goods.
4. Documents and certificate available in time.
5. Manual documents available. Engineer can be sent to client site for installation instruction.
