High Efficiency Powder Air Separator 2 - 150um
PROCESS
The MAC series is suitable for processing dry particulate materials and is capable of handing quantities from a few kilos/hour up to many tonnes/hour.
These forced vortex units are designed to operate either in closed-circuit with a conventional milling system or as independent ”stand-alone” systems incorporating feeder,fan and product collection equipment.
The product feed is introduced into the main air stream.Therefore the MAC classifier can be installed in existing air systems with a minimum of modification and will separate products of exceptional fineness and uniformity over a wide range of feed variations.
Entrained feed material enters through primary
air duct (1).
Cut point determined by control of rotor speed (and air flow).Particles are classified within the vortex as a result of the interaction between centripetal and air drag forces.Particles are introduced into a forced vortex generated within the machine by a rotor (2).
Particles below cut size pass through the rotor and exit with the entraining air duct (4) for collection in the external system.
Coarse particles above the cut point migrate to the casing wall and descend through the discharge cone (3) to outlet.
Secondary rinsing air enters through duct (5) dispersing agglomerated fines giving improved product yield.
Secondary air flow rate controls the residence time within the separating zone and can be adjusted to give optimum classification conditions for widely differing materials.
FEATURES
- Fine classification with high performance
- Belt drive
- Feed tangential in the classifying zone
- Adjustable secondary air system for optimisation of classification efficiency
- High feed rates possible
- Adjustment of cut point by variable rotor speed via frequency converter
- Construction material can be mild steel,stainless steel or wear protected
- Replaceable rotor blades and wear resistant rotor are available
- The solid construction give a long life time with low maintenance costs and low investment.
|
Type Parameters |
MAC0 |
MAC1 |
MAC2 |
MAC3 |
MAC4 |
MAC5 |
Product Fineness D97:um |
5~150 |
6~150 |
6~150 |
8~150 |
10~150 |
20~150 |
Throughput T/h |
0.05~0.5 |
0.2~1 |
0.5~3 |
1~5 |
2~8 |
5~10 |
Power kw |
4 |
7.5 |
11 |
15 |
22 |
30 |
Note: Capacity depends on material properties and final product fineness.
Chemicals, minerals (such as calcium carbonate, kaolin, classification of quartz, barite, talc, graphite and other non-metallic mineral products), ceramic, refractory material, medicine, pesticide, food, new materials and other industries.
Quality guarantee is for 18 months. During 18 months, if there is any problem or destroy (non-artificial damage), we will repair or change for free. After 18 months, if there is any problem, we will still supply good service, and we will charge cost if parts needed to be changed.
- Flow sheet of the process - Electrical interlocking sequence - Dimension drawings for supplied equipment - Operation manuals - Technical information and specification for local supply - Engineering drawings for local supplies - Technology data and drawings for installation and commissioning - Spare parts list
Other Main Products
Q &A:
1. Why choose QINGDAO SHINA as supplier?
A: QINGDAO SHINA has a perfect team with more than 20 years experience. Technology of QINGDAO SHINA is original from Germany. What customers get from QINGDAO SHINA is not only one set of machine, but together with know-how.
2. What should I do if I want to start a new project or extent production, but I have no idea what should I do at the beginning?
A. Please send email to QINGDAO SHINA and tell QINGDAO SHINA your situation of the project, QINGDAO SHINA will supply one feasibility study report together with detailed proposal and technical suggestions only for your project.
3. How about the quality of machine manufactured by QINGDAO SHINA?
A. QINGDAO SHINA business concept is: “Start a career with essence, win through high quality”. QINGDAO SHINA follows the principle of “quality is most important” when manufacturing each machine. Besides, QINDAO SHINA decides to lengthen quality guarantee of each machine or production line to 1.5 years so that customers can use machine without worry.
4. How about the after-sales service of QINGDAO SHINA?
A. QINGDA SHINA has a good after-sales service team, all the engineers in the team has more than 10 years experience. QINGDAO SHINA can promise that after the machine arriving at customer’s factory, we will arrange our engineer in time accordingly to make installation. Commissioning and test run. QINGDAO SHINA’s customer service concept is: customers are always the first!
5. How can I start the machine when getting machine?
A. QINGDAO SHINA will arrange engineers with rich experiences to customer’s factory for installation, commissioning and test run. After then, engineers will make training for workers about how to start machine or production line until workers can start machine very good alone.
6. If there are some problems or questions during running machine or production line, what should I do?
A. Please call QINGDAO SHINA in time if you have any questions during production. QINGDAO SHINA will reply customers in time to make sure the production won’t be delayed.
