Liquid Silicon Rubber Injection Molding Machine
US$ 1 - 15,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Preform Injection
Style:
Vertical
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhongshan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LSR Injection Molding MachineUS$ 1 - 15,000MOQ: 1 Set -
Led Bulb Manufacturing MachineUS$ 1 - 64,100MOQ: 1 Set
-
Polyurethane Rubber Injection Molding MachineUS$ 1 - 15,000MOQ: 1 Set
-
Rotary Injection Molding Machine Full Automatic Produce LED Lamp Bulb Base Quality ChoiceUS$ 1 - 33,000MOQ: 1 Set
-
Horizontal Injection Vertical Clamping Injection Molding MachineUS$ 1 - 60,000MOQ: 1 Set
Condition
New
Type
Preform Injection
Style
Vertical
Brand Name
YATAI
Model Number
V55S-LSR
Place of Origin
Guangdong, China
Plastic Type
Thermoplastic
Automatic
No
Injection Weight
0-142.2cm3
Injection Rate
103mm/s
Clamping Force
55ton
Opening Stroke
400mm
Power(W)
7.5kw
Certification
CE,ISO9001
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.Vertical type with 55ton clamping force2.Special designed for injecting lsr
| Model No. | V55S-LSR(Single Slide) | |||||
|
Injection Unit |
Screw Diameter | mm | 28 | 32 | 36 | |
| Theoretical Injection Volume | cm3 | 86 | 112.5 | 142.4 | ||
| Max.Injection Pressure | Mpa(kgf/cm2) | 153(1563) | 162(1661) | 127(1313) | ||
| Injection Rate | cm3/s | 88 | 83 | 105 | ||
| Injection Speed | mm/s | 103 | ||||
| Screw Speed Rotation | r.p.m | 0-240 | ||||
| Nozzle Out From Platens | mm | ≥45 | ||||
|
Clamping Unit |
Clamping Force | KN(tf) | 539(55) | |||
| Clamping Stroke | mm | 200 | ||||
| Min.Mold Thickness | mm | 120(200) | ||||
| Max.Opening | mm | 320(400) | ||||
| Distance Between Tie Bars | mm | 445*255 | --- | |||
| Max.Mould Size | mm | 380*376 | 380*376 | 300*300 | ||
| Platen/Slide Size | mm | 500*396 | 890*396 | 880 | ||
| Ejector Distance | mm | 70 | 70 | 70 | ||
| Ejector Force | KN(tf) | 21.5(2.2) | 26.5(2.7) | 26.5(2.7) | ||
| Others | System Pressure | Mpa(kgf/cm2) | 13.7(140) | 13.7(140) | 13.7(140) | |
| Oil Tank Capacity | L | 140 | 180 | 230 | ||
| Electric Power | KW(HP) | 7.5(10) | 11(15) | 11(15) | ||
| Machine Dimensions | L*W | mm | 2016*1265 | 1650*1380 | 1755*1598 | |
| H | mm | 2465(3110) | 2460(3105) | 2560(3205) | ||
| Machine Weight | tf | 1.8 | 2.2 | 2.7 | ||
1. Provide free guidance of before you start use our injection molding machine
2. 1 year warranty
3. Free remote guidance by video chat when you have problem during use the injection molding machine
1. Before shipping,we will check and test the machine carfully
2. We will arrange to manufacture the second day after confirmation,we can delivery it usually after 25 days
3. According to the destination,we will compare several transportation companies and select the most suitable and economic one to provide service for us
