Home > Manufacturing & Processing Machinery > Plastic Machinery > Injection Molding Machine > Plug Injection Molding Machine
US$ 1 - 8,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Preform Injection
Style:
Vertical
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhongshan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2 Stations Rotary Injection Molding MachineUS$ 1 - 33,000MOQ: 1 Set -
PVC Injection Molding MachineUS$ 1 - 8,000MOQ: 1 Set
-
Beach Table Top Injection Molding MachineUS$ 1 - 8,000MOQ: 1 Set
-
Socket Plug Verticaal Injection MachineUS$ 1 - 8,000MOQ: 1 Set
-
Vertical 2 Station Plastic Injection Molding MachineUS$ 1 - 40,000MOQ: 1 Set
Condition
New
Type
Preform Injection
Style
Vertical
Brand Name
Yatai
Model Number
V35
Place of Origin
Guangdong, China
Plastic Type
Thermoplastic
Automatic
Yes
Injection Weight
49-80g
Injection Rate
116-186mm/s
Clamping Force
35ton, 35ton
Opening Stroke
350-400mm
Power(W)
9.1kw
Certification
CE,ISO9001:2008
After-sales Service Provided
Overseas service center available
Specifications
1. Small vertical type2. 35ton clamping force
3. 15-500ton also available
4. important parts imported from overseas
| Model No. | V35 | |||||
Injection Unit | Screw Diameter | mm | 22 | 25 | 28 | |
| Theoretical Injection Volume | cm3 | 53 | 68.8 | 86 | ||
| Injection Weight(PS) | g(oz) | 49(1.7) | 63.8(2.2) | 80(2.8) | ||
| Max.Injection Pressure | Mpa(kgf/cm2) | 248(2530) | 192(1960) | 153(1563) | ||
| Injection Rate | cm3/s | 44 | 57 | 71 | ||
| Injection Speed | mm/s | 116(186) | ||||
| Screw Speed Rotation | r.p.m | 0-300 | ||||
| Nozzle Out From Platens | mm | ≥45 | ||||
Clamping Unit | Clamping Force | KN(tf) | 343(35) | |||
| Clamping Stroke | mm | 200 | ||||
| Min.Mold Thickness | mm | 150(200) | ||||
| Max.Opening | mm | 350(400) | ||||
| Distance Between Tie Bars | mm | 370*210 | ||||
| Max.Mould Size | mm | 350*340 | ||||
| Platen/Slide Size | mm | 500*360 | ||||
| Ejector Distance | mm | 40 | ||||
| Ejector Force | KN(tf) | 17.2(1.75) | ||||
| Others | System Pressure | Mpa(kgf/cm2) | 13.7(140) | |||
| Oil Tank Capacity | L | 130 | ||||
| Electric Power | KW(HP) | 5.5(7.5) | ||||
| Heater Power | KW | 3.6 | ||||
| Machine Dimensions | L*W | mm | 1539*1152 | |||
| H | mm | 2196(2811) | ||||
| Machine Weight | tf | 1.3 | ||||
1. Before shipping,we will check and test the machine carfully
2. We will arrange to manufacture the second day after confirmation,we can delivery it usually after 25 days
3. According to the destination,we will compare several transportation companies and select the most suitable and economic one to provide service for us
1. Provide free guidance of before you start use our injection molding machine
2. 1 year warranty
3. Free remote guidance by video chat when you have problem during use the injection molding machine
Send Inquiry to This Supplier
* Email
Want the best price?
Post an RFQ now!
Business Type
Manufacturer
Year Established
2007
Factory Size
10,000-30,000 square meters
Total Employees
101 - 200 People
