220T Good Horizontal Injection Molding Machine H220SD

Name: 220T Good Horizontal Injection Molding Machine H220SD
Brand: Qianke
SKU: 111078221

US$ 1,500 - 80,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Preform Injection

Style:

Horizontal

Zhongshan Yatai Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Zhongshan

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Preform Injection

Style Horizontal

Brand Name Qianke

Model Number H220SD

Place of Origin Guangdong, China

Plastic Type Thermoplastic

Automatic Yes

Injection Weight 382-570g

Injection Rate 130-205mm/s

Clamping Force 220Tf, 120-500Ton

Opening Stroke 450mm

Certification CE

After-sales Service Provided Overseas service center available

Specifications

1.Clamping force120-500tons
2.Vertical clamping,Vertical injection,easy to insert
3.Famous brand in each parts.
4.Yuken,Omron

1,Specifications

			Unit	H220SD
Injection Unit	Screw Diameter		mm	45 50 55
	Theoretical Injection Volume		cm3	382 471 570
	Injection Weight(PS)		g(oz)	355(12.5) 438(15.4) 530(18.7)
	Max.Injection Pressure		Mpa(kgf/cm2)	244(2489) 198(2016) 163(1666)
	Injection Rate		cm3/s	207 255 309
	Injection Speed		mm/s	205 165 130
	Screw Speed Rotation		r.p.m	0-220
Clamping Unit	Clamping Force		KN(tf)	2156(220)
	Clamping Stroke		mm	450
	Min.Mold Thickness		mm	350
	Max.Opening		mm	800
	Distance Between Tie Bars		mm	910*450
	Max.Mould Size		mm	650*620
	Diameter of Rotary Table		mm	---
	Ejector Distance		mm	125
	Ejector Force		KN(tf)	56.8(5.8)
Others	System Pressure		Mpa(kgf/cm2)	17.2(175)
	Oil Tank Capacity		L	580
	Electric Power		KW(HP)	30(40)
	Heater Power		KW	13
	Machine Dimensions	L*W	mm	4625*2450
		H	mm	3320
	Machine Weight		tf	13
