Home > Manufacturing & Processing Machinery > Plastic Machinery > Injection Molding Machine > 2013 Injection Molding Machine-making Shoes/sole Series Quality Choice
2013 Injection Molding Machine-making Shoes/sole Series Quality Choice
US$ 2,000 - 80,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Preform Injection
Style:
Vertical
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhongshan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2013 Vertical Injection Molding Machine -Double ColorUS$ 2,000 - 80,000MOQ: 1 Set -
2013 Injection Molding Machine -YT-C85T-CUS$ 2,000 - 80,000MOQ: 1 Set
-
2013 LSR Injection Molding MachineUS$ 4,000 - 80,000MOQ: 1 Set
-
Vertical Injection Molding MachineNegotiableMOQ: 1 Set
-
2013 Vertical Injection Molding MachineUS$ 5,000 - 800,000MOQ: 1 Set
Condition
New
Type
Preform Injection
Style
Vertical
Brand Name
YATAI
Model Number
YT-220T-G
Place of Origin
Guangdong, China
Plastic Type
Thermoplastic
Automatic
Yes
Injection Weight
530g
Injection Rate
0-220
Clamping Force
220T
Opening Stroke
450mm
Power(W)
37.5KW
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
.1.High efficiency and stable injection.2.Most famous component parts.YUKEN.
3.Vertical injection molding machine.
| YT-220T-G | 1 | 2 | 3 | ||
| Injection Unit | Clamping force (Tf ) | 220 | |||
| Screw Diameter (mm) | 45 | 50 | 55 | ||
| Injection Volume (cm3) | 276 | 350 | 432 | ||
| Injection Weight(PS) (g) | 355 | 438 | 530 | ||
| Injection Pressure (kg/cm2) | 2489 | 2016 | 1666 | ||
| Screw Speed (RPM) | 0~220 | ||||
| Clamping Stroke (mm) | 450 | ||||
| Clamping Unit | Space Between Tie-Bars(mm) | 910x450 | |||
| Min Mould Thickness (mm) | 350-400 | ||||
| Max Mould thickness (mm) | 800-850 | ||||
| Ejection Force (Tf) | 5.8 | ||||
| Ejection Stroke (mm) | 150m |
||||
| Others | Motor Power (kw) | 30 | |||
| Heater Power (kw) | 13 |
||||
| Dimenshion(LxWxH) m | 4.0x1.6x3.4m | ||||
| Machine Weight (kg) | 9700 | ||||
| Proportional Valve | Yuken Brand | ||||
| Hydraulic oil pump | Yuken Brand | ||||
Main advantage:
1.High efficiency and stable injection.
2.Most famous component parts(YUKEN OR HNC Valve).
3.Vertical injection molding machine.
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
2007
Factory Size
10,000-30,000 square meters
Total Employees
101 - 200 People
