2013 Vertical Plastic Injection Molding Machine-YT-V85T-GS
US$ 2,000 - 8,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Preform Injection
Style:
Vertical
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhongshan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2013 Vertical Injection Molding Machine -YT-C55T-C-power CordUS$ 20,000 - 900,000MOQ: 1 Set -
2011 Injection Molding MachineNegotiableMOQ: 1 Set
-
2011 Injection Molding MachineNegotiableMOQ: 1 Set
-
2011 Injection Molding MachineNegotiableMOQ: 1 Set
-
2013 Injection Molding Machine -Tie Barless Horizontal InjectionUS$ 2,000 - 80,000MOQ: 1 Set
Condition
New
Type
Preform Injection
Style
Vertical
Brand Name
YATAI
Model Number
YT-V85TR-GS
Place of Origin
Guangdong, China
Plastic Type
Thermoplastic
Automatic
Yes
Injection Weight
30.6g
Injection Rate
0-380
Clamping Force
85T
Opening Stroke
250
Power(W)
15kw(MOTOR)
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.Famous component parts .YUKEN,2.Safety operation, Round base deisgn ,
injected molding with two time in one circle.
| Model No. | YT-V85T-GS | |||
| Specifications | 1 | 2 | ||
| Injection Unit | Clamping force (Tf ) | 120 | ||
| Screw Diameter (mm) | 22 | 26 | ||
| Injection Volume (cm3) | 26.7 | 32.9 | ||
| injection Weight(PS) (g) | 26 | 30.6 | ||
| Injection Pressure (kg/cm2) | 2811 | 2100 | ||
| Screw Speed (RPM) | 0~380 | |||
| Clamping Unit | Clamping stroke (mm) | 250 | ||
| Min.Mould Thickness (mm) | 230-330 | |||
| Max .Mould Thickness (mm) | 480-580 | |||
| Ejection Force (Tf) | 2.7 | |||
| Ejection Stroke (mm) | 50 | |||
| Others | Motor Power (kw) | 11(380-415V~) | ||
| Heater Power (kw) | 5.6 | |||
| Dimenshion(LxWxH) m | 3.5x1.5x2.5 | |||
| Machine Weight (kg) | 5000 | |||
1.Famous component parts (YUKEN .NHC)
2.Safety operation, Round base deisgn .
injected molding with two time in one circle.
3.Saving energy and high efficiency .
