850tf Horizontal Injection Molding Machine
US$ 5,000 - 30,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Preform Injection
Style:
Horizontal
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhongshan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Medical Supplies Injection Molding MachineUS$ 1 - 80,000MOQ: 1 Set -
Hydrauic Injection Molding Machine Cylinder Injection High PreciseUS$ 10,000 - 50,000MOQ: 1 Set
-
Injection Molding MachineUS$ 7,000 - 30,000MOQ: 1 Set
-
350tf Horizontal Injection Molding MachineUS$ 5,000 - 30,000MOQ: 1 Set
-
180tf Horizontal Injection Molding MachineUS$ 5,000 - 30,000MOQ: 1 Set
Condition
New
Type
Preform Injection
Style
Horizontal
Brand Name
YaTai
Model Number
NCII-850
Place of Origin
Guangdong, China
Plastic Type
Thermoplastic
Automatic
Yes
Injection Weight
3467 4195 4992g
Injection Rate
77mm/s
Clamping Force
850tf, 850tf
Opening Stroke
1600mm
Power(W)
139.75kw
After-sales Service Provided
Overseas service center available
Specifications
1.Horizontal clamping,Vertical injection,easy to insert2.Full-automatic insert molding
3.The cooling time can be shortened
| Item | Unit | NCII-850 | ||
| Screw Diameter | mm | 100 | 110 | 120 |
| Injection Weight(P.S.) | g | 3467 | 4195 | 4992 |
| oz | 122 | 148 | 176 | |
| Injection Pressure | kgf/cm2 | 2640 | 2181 | 1833 |
| Length/Diameter Ratio | L/D | 22 | 20 | 18 |
| Injection Speed | 77 | |||
| Injection Rate | mm/sec | 606 | 733 | 872 |
| Screw Speed | r.p.m | 90 | ||
| Plasticizing Capacity(P.S.) | kg/hr | 100 | 530 | 590 |
| Hopper Capacity | kg | 100 | ||
| Mold Opening Force | ton | 29.8 | ||
| Mold Opening Stroke | ton | 850 | ||
| Mold Clamping Force | mm | 1600 | ||
| Min.Mold Thickness | mm | 500 | ||
| Max.Daylight Opening | mm | 2100 | ||
| Distance Between Tie Bars | mm | 1060*1060 | ||
| Mold Plate Dimension | mm | 1560*1560 | ||
| Ejector Force | ton | 25.4 | ||
| Ejector Stroke | mm | 250 | ||
| Ejector Quantity | p.c.s | 29 | ||
| Pump Motor | kw(HP) | 96(130) | ||
| Heater Band Capacity | kw | 43.75 | ||
| No.of Heating Zone | Nozzle+5 | |||
| Oiltank Capacity | L | 2250 | ||
| Machine Dimension(L*W*H) | m | 11.6*2.42*2.26 | ||
| Machine Weight | ton | 40 | ||
Zhongshan Yatai Machinery Co., Ltd. is biggest wire processing factory in the area of perl river delta region ,Specialized in R&D and producing plastic injection molding machines, full auto wire stripping crimping machines, cutting stripping machines, tube cutting machines and automatic robot hands.If you want to know more about our pruducts,please browse the website as follows
/
