Top10 IR Camera ,Varifocal IR CCTV CCD Dome Camera,Surveillance CCTV

Name: Top10 IR Camera ,Varifocal IR CCTV CCD Dome Camera,Surveillance CCTV
Brand: Aliviz
SKU: 111050185

US$ 20 - 40 MOQ: 10 Pieces

Key Specifications

Place of Origin:

China

Brand Name:

Aliviz

Model Number:

AS-D3183IR

Aliviz Security (Shenzhen) Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name Aliviz

Model Number AS-D3183IR

Type Analog Camera

Style Dome Camera

Sensor CCD

Technology Infrared

Special Features Waterproof / Weatherproof

Specifications

Varifocal IR Dome Camera,Surveillance CCTV Dome Camera

FEATURES

1. 1/3'' Sony CCD camera;

2. IR CCTV Dome Camera built in 36PCS, 5mm IR LEDs and IR distance can up to 30M

3. 2.8-12mm manual zoom lens is optional;

4. Standard: 4-9mm manual zoom lens;

SPECIFICATIONS

30M IR Dome Camera
Model	AS-D3183IR-700	AS-D3183IR-600	AS-D3183IR-540	AS-D3183IR-480	AS-D3183IR-420
Image Sensor	1/3" SONY ICX673AK CCD	1/3" SONY ICX639BK CCD	1/3" SONY ICX639BK CCD	1/3" SONY ICX633BK CCD	1/3" SONY ICX633BK CCD
Horizontal Resolution	700TVL Effio, ATR, OSD NR	600TVL OSD	540TVL	480TVL	420TVL
TV System	PAL/NTSC
Effective Pixels	976 (H)X494(V)	795 (H)X596(V)		752(H)x582	PAL:500(H)x582(v)
					NTSC:510(H)x492(v)
IR LED	36pcs Ø5mm IR LEDs
IR distance	30 meters
Lens	standard: 4-9mm manual zoom lens
	2.8-12mm manual zoom lens is optional
Minimum Illumination	0 Lux/F2.0 (LED ON)
IR Status	Under 10 Lux by CDS
IR Power On	CDS Auto Control
Scanning System	NTSC:525 Lines,60 Field/sec,
	PAL:625 Lines 50 Field/sec
Sync System	Internal Synchronization
S/N Ratio	54dB (AGC OFF)			48dB (AGC OFF)
Electronic Shutter Time	NTSC 1/60~1/100,000Sec,PAL 1/50~1/100,000Sec;
Video Output	Composite Signal (1.0Vp-p, 75O), BNC
Gain Control(AGC	Auto
White Balance	Auto
Backlight Compensation	Auto
Operation Temperature	-10C~ +50C RH95% MAX
Storage Temperature	-20C~ +60C RH95% MAX
Waterproof	IP66
Power Supply	DC12V,400mA
Dimension	Ø135X83(H)mm
Housing Color	White or Black
weight	0.9 kg
