Milling Machine

Specifications

                                                      Micro miller Machine

Introduction:

This impact suction type rice flour miller is an efficient micro-mill, crushing and grading of silt materials installed on the same machine body, and independent operation. The machine has a full-featured , compact structure , stable technical performance , power consumption province , to adapt to a wide range of , not produce crushed powder fineness adjustable , easy maintenance, and other characteristics , widely used in chemicals, dyes , paints , pharmaceuticals , food other various sectors do not have the field of ultrafine pulverized material pulverized and graded to the finished product is carried out in the same closed system , after the dust removal processing , no pollution, environmental ideal machine .

Main Structures:

By hopper , crushing system ,fan blade device , suction dust removal system and the induced draft system, driving device composed of grinding chamber, hopper , crushing blade , gear ring , sieve , fan blade , discharging by suction pipeline , cyclone , air clock , dust filter bag , induced draft fan and so on .

Working Principle:

The raw material enters into the grinding chamber through the feed hopper. The material, impacted by the high-speed rotary cutters, is thrown to the fixed liners, then is bounced and sheared. Meanwhile, under the impact, cut, rub force by turns, the material is micronized well. Under the pull force, the finished products are absorbed into the cyclone through the sieve. A little of superfine powder is collected by the pulse dust remover.
