Advanced lab food extruder
- 30 Set / Sets per Month
- QINGDAO
- T/T
You May Like
Product Details
Place of Origin | Shandong, China | Brand Name | SAIBAINUO | |
Model Number | SYS30--IV | Type | Other, lab food extruder machine | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
High Quality Low Consumption lab food extruder
Product Description
Lab twin-screw extruder is our company research for universities, research institutes and large and medium-sized enterprises engaged in various extrusion, extruded maturation, extruded variability study omnipotent models.
It has gone through four generations of improvements to adapt to cereals, potato starch, protein, chemicals, plastics, rubber and other raw materials are vastly different for a variety of experiments. Powerful, easy to operate and simplely of parameters adjustment, test data accurate, easy maintenance .
Lab twin-screw experiment extruder
Characteristic
1, The screws are made by ally steel and special craft, the screw life is longer, uses building block system structure, may combine willfully.
2, The forced lubrication system, by guaranteed equipment transmission longer life.
3, Visible auto-temperature controlling system, make the temperature-controlling to be more direct-viewing, parameter to be more precise.
4, Screw speed and wide temperature range :screw speed arbitrary adjustments between 0 and 500 RPM. temperature arbitrary regulation at room temperature to 300 degrees.
Engine power | 5.5KW | Second series L/D | 9.3 15 20.6 | Pressure scope | 0-30MPa |
Engine speed-control | Frequency speed-control | Heating way | Heating ring | Pressure precision | 0.1MPa |
Screw diameter | 30 | Cooling way | Water | Number of measuring pressure | 3 |
Screw central distance | 26mm | Temperature scope | 20°C-300°C | Model cooling way | Water |
Speed range | 0-500rpm | Temperature precision | ±1.0°C | Filling intake | 3 |
Screw mode | Building block-combined type | Number of measuring temperature point | 4 | Water intake | 3 |
First series L/D | 11.6 12.7 23 | Output | 10-25KG/H | Percent of water | 6%-7% |
Machine material
All the machines are made by Stainless steel 201,which can reach the sanitary food grad.If you have special requirement, we also have ss304,ss316 for your demand.
Voltage
Chinese three phase Input Voltage is 380V/ 50Hz,single phase Input voltage is 220v/50Hz. If it’s different from your local power,you can tell us before the order,so we can change the voltage and Hertz as your demand.
Jinan Saibainuo Technology Development Co.,Ltd. is a professional manufacturer specializing in on the development of inflating food machines, botanical protein machines,prt foodstuff machines and experimental extruding machines. We have lots of masters and professional backbone who have devoted themselves to this industry. We also possess outstanding engineers and high-qualified installing workers.
1. When we received your deposit of this order, we will ask our engineers to prepare to apply the visa, when the processing line arrived your country, and we will send two engineers to go and help you to install the line, teach your worker(3-4 workers) how to operate the line, until your worker know the line well.
2.Our engineers has responsibility to teach your worker how to clean the extruder, how to change the screw, how to change barrel etc. and we have responsibility to provide technology support with you forever.
3. Our engineers can provide basic formula for producing the food. and help customer to produce good quality food according customer’s detailed formula.
4.We provide the spare parts will at preferential price for an extended long time.
Packed by standard Fumigation wooden case outside and wrapped by plastic film inside then shipped b container,which is suitable for long time sea shippment.
We-Saibainuo Company have the certification of CE SGS ISO etc.Welcome to contact with Me
How to choose a good supplier for extruder food machinery?
1.As you are the machine user,so the machine quality is the most import.You must cooperate with the supplier who can provide you high quality extruder food machine.
2.The supplier you choose must be the directly manfacturing factory,they must have big technical design team with many years experience in extrusion production field and provide you the real extrusion technology.
3.After you choose the manufacturing factory,they must have professional design team who can design processing layout that are suitable for your workshop.
4.After you place order,during they produce machine for you,first their machineparts must be in high quality,second,their workers must be many years experience for machine production,third,they must have quality control personnel for machine inspection during and after machine finish.
5.The factory must can provide you best after-sales service and also machine installation for you when machine reached to your factory.The factory must have big workshop for enough spare parts in store.In case you need spare parts in the future,they can provide for you on time.
