Cost Effetive and Reliable DM60xxE, 2-phase Hybrid Stepper Motor
US$ 40 - 50
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
Leetro
Model Number:
DM60xxE
Payment & Shipping
Payment Methods:
Port of Shipment:
Chengdu
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2-phase Hybrid Stepper/stepping Motor (DM56xxE)US$ 22 - 32MOQ: 1 Piece -
2-phase Hybrid Stepper/stepping Motor (DM42xxE)US$ 14 - 30MOQ: 1 Piece
-
2-phase Hybrid Stepper/stepping Motor (DM39xxE)US$ 12 - 19MOQ: 1 Piece
-
2-phase Hybrid Stepper/stepping Motor (DM35xxE)US$ 12 - 22MOQ: 1 Piece
-
2-phase Hybrid Stepper/stepping Motor (DM28xxE)US$ 19 - 25MOQ: 1 Piece
Place of Origin
Sichuan, China
Brand Name
Leetro
Model Number
DM60xxE
Phase
2
Type
Hybrid
Step Angle(degrees)
1.8
Holding Torque
1.10-3.10 Nm
Current / Phase
2.1-8.34 A
Item |
Specifications. |
Step Angle |
1.8° |
Step Angle Accuracy |
±5% (full step, no load) |
Resistance Accuracy |
±10% |
Inductance Accuracy |
±20% |
Temperature Rise |
80C Max. (rated current, 2 phase on) |
Ambient Temperature |
-20~+50C |
Insulation Resistance |
100MΩMin., 500VDC. |
Dielectric Strength |
500VAC for one minute |
Shaft Radial Play |
0.02Max. (450 g-load) |
Shaft Axial Play |
0.08Max. (450 g-load) |
Max. radial force |
75N (20mm from the flange) |
Max. axial force |
15N |
| Model | Parallel /Series | Rated | Current | Resistance | Inductance | Holding | Rotor | Weight | Length |
| Voltage | /Phase | /Phase | /Phase | Torque | Inertia | ||||
| (V) | (A) | (Ω) | (mH) | (Nm) | (gcm2) | (Kg) | (mm) | ||
| DM6047E | P | 2.1 | 2.8 | 0.75 | 2.0 | 1.10 | 275 | 0.60 | 47 |
| S | 4.2 | 1.4 | 3.0 | 8.0 | |||||
| DM6056E | P | 2.52 | 2.8 | 0.9 | 3.6 | 1.65 | 300 | 0.77 | 56 |
| S | 5.04 | 1.4 | 3.6 | 14.4 | |||||
| DM6067E | P | 3.36 | 2.8 | 1.2 | 4.6 | 2.10 | 570 | 1.2 | 67 |
| S | 6.72 | 1.4 | 4.8 | 18.4 | |||||
| DM6088E | P | 4.17 | 2.8 | 1.5 | 6.8 | 3.10 | 840 | 1.4 | 88 |
| S | 8.34 | 1.4 | 6.0 | 27.2 |
| Model | Leetro Drivers | ||
| DM6047E |
DM403A, DMD605 |
||
| DM6056E | |||
| DM6067E | |||
| DM6088E | |||
Packaging & Shipping
DHL, TNT, FedEx air express
sea shipping is available under request
Our Services
12-month product warranty
