Home > Manufacturing & Processing Machinery > Mining Machinery > Mining Crusher > Hammer Crusher

Hammer Crusher

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

Used

Year:

2008

Type:

Hammer Crusher

Contact Supplier Request Quote Chat Now

Jiangsu Pengfei Group Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition Used

Year 2008

Type Hammer Crusher

Motor Type AC Motor

Power(W) 500 KW

Capacity(t/h) 220-280

Place of Origin Jiangsu, China

Brand Name PF

Model Number PC

Warranty 1

Specifications

Hammer Crushe is suitable to crush all kinds of brittle minerals such as coal, salt, chalk, gypsum, alum, brick, tile, lime ston

Hammer Crusher is suitable to crush all kinds of brittle minerals such as coal, salt, chalk, gypsum, alum, brick, tile, lime stone and so on whose compressive strength does not exceed 100 Mpa.

This machine mainly is made up of the frame, rotor, sieve, hammers and other parts. Motor can directly drive

the rotating hammers of the Hammer Crusher with high rotation speed.

Main technical parameters

MODEL	Work rotor diameter / length(mm)	Rotor Speed (r/min)	Inlet Size (mm)	Max. feeding size(mm)	Discharge size (mm)	Capacity (t/h)	Motor Power (kw)	Weight (t)	Dimensions (mm)
PC-41	400/175	1000	145×270	50	3	0.5	5.5	0.5	812×1056×1315
PC-44	400/400	1500	145×450	100	10	5~8	7.5	0.9	744×942×878
PC-64	600/400	1000	295×450	100	15	10~12	18.5	1.03	1054×972×1117
PC-66	600/600	1000	295×570	100	10	12~18	45	2.14	1315×840×1501
PC-86	800/600	1000	350×570	200	10	20-25	55	2.45	1515×2586×1040
PC-88	800/800	1000	350×850	200	15	35-45	55	3.05	1515×2831×1040
PC-108	1000/800	1000	580×850	200	13	25-40	110	6.5	3206×2210×1515
PC-1010	1000/1000	1000	580×1060	200	15	40-60	132	7.59	3514×2230×1516
PC-1010	1000/1000	1000	580×1060	200	10	30-50	160	7.59	3514×2230×1518
PC-1010	1000/1000	1000	580×1060	200	8	25-35	185	7.59	3514×2230×1518
PC-1212	1250/1250	750	650×1330	200	20	90-110	185	19.1	4475×3162×2250
PC-1414	1400/1400	750	1050×1540	250	20	120-170	280	17.2	2790×2800×2310
PC-1618	1600/1800	590	1200×1740	350	20	220-280	500	32.4	6256×3620×2700
