We, Jiangsu Pengfei Group Co., Ltd supply complete equipments for active lime production line with capacity below 1200 ton per day. The active lime is widely used in steel production, Al2O3 production, Metal Mg production, calcium carbide and Power plant desulfurization paper production area. Active lime is an important auxiliary material in steel making industry. The using of active lime enhances the quality and capacity and lower down the loss and cost. It also stabilizes the operation. As proved in production, the using of active lime in steel making industry is very profitable. Recently years, the capacity of steel industry used lime increased by 40%. High quality lime with activity above 300ml increased from 27% to 29.5%.
Process and equipment
1.Raw material conveying system
2.Active lime calcining system
3.Pulverized coal preparation system
4.Finished product conveying system
5.Flue gas treatment system
6.Product quality
CaO ≥ 93, MgO ≤ 4.5, SiO2 ≤ 1, P ≤ 0.01, S ≤ 0.025 ignition loss ≤ 3, active degree ≥ 350ml ~ 380ml ≤ 1.5%, burning, burning ≤ 1.5%.
Technical Active lime rotary kiln system process matching table
| specification | dia2.5×40 | 2.8x42 | 3x46 | 3.2x50 | 3.2x54 | 3.6x56 | 3.8x58 | 4x60 | 4.3x58 | 4.3x64 | 4.8x68 |
| volume(m3) | 142 | 190 | 235 | 292 | 390 | 430 | 505 | 575 | 670 | 738 | 1005 |
| burning temperature0C |
1350/ 1250 |
1350/ 1250 |
1350/ 1250 |
1350/ 1250 |
1350 | 1350 | 1350 | 1350 | 1350 | 1350 | 1350 |
| capacity(t/d) | 150 | 200 | 250 | 300 | 350 | 400 | 500 | 600 | 750 | 800 | 1000 |
Main equipment
| NO. | Equipment name | Specification | Type | Qty | |
| 1 | rotary kiln | dia4.0×60m | 1 | ||
| 2 | vertical preheater | dia10.5×8.5m | 1 | ||
| 3 | vertical cooler | 105m3 | 4.2*9m |
1 | |
| 4 | multi pipe cooling machine | dealing air:260000m3/h |
1 | ||
| 5 |
High temperature exhaust fan
|
900kw,10KV
|
1 | ||
| 6 | coal mill system | 8-10t/h | PDM1250 | 1 | |
| 7 | gas&coal burning system | four way burner | 1 | ||
| 8 | dust collector equipment | ||||
| 8.1 | kiln tail flue dust collector | dealing air :260000m3/h | LCMD-3660 | 1 | |
| 8.2 | coal grinding dust collector | dealing air:45000m3/h | FGM128-6(M) | 1 | |
| 8.3 | cooling dust collector | dealing air:18600m3/h | PPc64-4 | 1 | |
| 8.4 | finished product screening dust collector | dealing air:18600m3/h | PPc64-4 | 1 | |
| 9 | accessory equipment | ||||
| 9.1 | bucket elevator | NE100 | 1 | ||
| 9.2 | Circular vibrating screen | YA1536 | 1 | ||
| 9.2 | Circular vibrating screen | YA1236 | 1 | ||
| 9.4 | chain scraper conveyor | DS500 | 1 | ||
| 9.5 | belt conveyor | 6 | |||
| 10 | fan | ||||
| 10.1 | axial flow fan | 4 | |||
| 10.2 | centrifugal fan | 2 | |||
| 10.3 | coal mill fan | 1 | |||
| 10.4 | roots fan | 3 | |||
