Paper Machinery for Cutting Paper

Paper Machinery for Cutting Paper photo-1
Paper Machinery for Cutting Paper photo-2
Paper Machinery for Cutting Paper photo-3
Paper Machinery for Cutting Paper photo-4
Paper Machinery for Cutting Paper photo-5
Paper Machinery for Cutting Paper photo-6
US$ 8,000 - 12,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Paper Cutting Machine
Computerized:
Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghi
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Paper Cutting Machine
Computerized Yes
Place of Origin Hubei, China
Brand Name Dongfang
Model Number QZK(X)1300W etc.
Voltage 380V 50Hz, 220V/380V
Power(W) 3KW
Dimension(L*W*H) 2688*2460*1520
Weight 4000Kg
Certification ISO9001
Warranty 1year
After-sales Service Provided Engineers available to service machinery overseas

Paper machinery for cutting paper

Product Description

Technological Features:

    1. Drivetrain system:

       Planar double-enveloping worm gearing; High efficiency, energy saving and little noise

   2. Workbench:

       Slotless chroming workbench; dual rail paper-pusher, vertical and parallel adjustment system of paper-pusher is separated, simple and accurate.

    3. Hydraulic system:

       Hydro-cylinder with Italian technology; Selection of hydraulic components meets the ISO standard.

    4. Security System:

       Infrared protection device; cutter block security system, overload protection and two hands operation device

    5. Knife bar push out device



Application:

    The paper cutter is used for cutting various kinds of printing paper materials,paperboard,plastic,leather,cloth and metallic foil,etc with  high accuracy high accuracy.



Main Type:

    The main Paper cutting machine type is showed as below, and we also can produce and design according to consumer’s special requirements.



   QZK(X)920S  QZK(X)920B  QZK(X)920W  QZK(X)1300W QZK(X)1370W
Max. Cutting width(mm)  920  920  920  1300 1370
Max. Cutting height(mm)  115  115  120  130 165
Cutting Speed(times/min)  30  40  40  45 45
Max clamping pressure(N)  28000  35000  35000  45000 45000
Total power(KW)  4.1  4.3  4.3  5.5 5.85
Overall Dimensions(mm)   2280×1100×1760   2210×1230×1735   2280×1400×1850  2730×1350×1830 2950×1400×2000
Gross Weight(KG)  2000  2200  2600 4000 4500
Drivetrain System  Gear  Worm gearing  Worm gearing  Worm gearing Worm gearing
Blade Size(mm)   1065×127×12.7   1065×127×12.7   1100×127×12.7  1520×127×12.7 1605×160×13.75



Detail & Factory:Paper machinery for cutting paper

Packaging & Shipping



   The paper cutter machine is packaged in  wooden crate and it is separated to two parts:the body of machine and the workbench.

   All the parts are fix on to the wooden crate to make sure that it will not hurt during the transportation.(as it showed in pic)

   We export by Shanghi Port usually!

Paper machinery for cutting paper

FAQ

    any question.please contact.

      Do you have other type? yes ,we can make other type paper cutting machine like 920/1300/1370/1500/1550 etc.



Guarantee and after sale Service:



  • one year for whole machine
  • 24 hour technical support by email
  • friendy english content and instructions about the machine
