ZK-120B extrusion blow molding machine
Blow molding machine ZK-120B suits for making big-huge plastic toy houses, fences, sliders,educational furniture...
Machine technical specifications:
technical parameters |
|
ZK-120B |
specification |
unit |
|
max container capacity |
L |
220 |
machine dimension |
M |
7.5*3.2*5.1 |
total weight |
ton |
22 |
clamping system |
|
|
clamping force |
KN |
1200 |
plate opening stroke |
mm |
600-1600 |
max mould size(W*H) |
mm |
1200*1600 |
mould thickness |
mm |
610-850 |
power |
|
|
max drive |
KW |
22 |
total power |
KW |
175 |
fan power for screw |
KW |
0.72 |
air pressure |
Mpa |
0.7 |
air consumption |
m3/min |
0.9 |
average energy consumption |
KW |
55 |
extruder unit |
|
|
screw diameter |
mm |
120 |
screw L/D ratio |
L/D |
28:1 |
plasticizing capacity |
kg/hr |
280 |
number of heating zone |
zone |
6 |
extruder heating power |
KW |
35 |
extruder driving power |
KW |
75 |
accumulator head |
|
|
number of heating zone |
zone |
6 |
power of die heating |
KW |
50 |
max die-pin diameter |
mm |
600 |
accumulator volume |
L |
30 |
Case show presentation:
molding machine; Blow molding machine; PE blow molding machine;PP blow molding machine;ABS blow molding machine;HDPE blow molding machine; EVA blow molding mahicne; Automatic blow molding machine;Single screw blow molding machine; Double screw blow molding machine;Educational toy house;, medical bed; bed hoard,head board,footboard Plastic water tank; 1000L tank; 500L tank;2000L tank; Septic tank; 60L drum; 220L barriel;50gallon barrel; 20L jerry can; HDPE IBC;
