Help CenterZG Series Vacuum Freeze Dryer
Related Products
-
Haichuan Vacuum Food and Other DryersUS$ 1,000 - 100,000MOQ: 1 Set -
High-quality Large Capacity Vacuum Freeze Drying MachineUS$ 30,000 - 380,000MOQ: 1 Set
-
High Speed Centrifugal Spary DrierNegotiableMOQ: 1
-
ZG-1Vacuum Mini Freeze DryerUS$ 1,000 - 100,000MOQ: 1 Set
-
Vacuum Freeze DryerUS$ 1,000 - 100,000MOQ: 1 Set
The vacuum freeze dryer is a advanced method of dehydration,whose process takes advantage of the principle of ice crystal's lyopilization under purified vacuum condition ,in which the water inice form on the frozen goods can be directly lyophilized into steam without melting in advance ,thus the goods are dried .
| type | ZG-0.5 | ZG-1 | ZG-2 | ZG-3 | ZG-5 | ZG-8 | ZG-10 | |
| Drying oven size(φxL) | 0.5x0.5 | 0.7x0.7 | 0.8x0.9 | 0.9x1.0 | 1.0x1.2 | 1.1x1.5 | 1.2x1.5 | |
| Effective shelf area(m2) | 0.5 | 1 | 2 | 3 | 5 | 8 | 10 | |
| Shelf working temperature(°C) | -45~60 | |||||||
| Shelf temperature difference(°C) | ±1 | |||||||
| Condenser temperature(°C) | -50~60 | |||||||
| Condenser water catching (Kg) |
7 | 12 | 25 | 40 | 60 | 100 | 120 | |
| The highest vacuum(Pa) | 3 | |||||||
| cooling water(≤25°C)flow(T/h) | 1 | 2 | 3 | 5 | 5 | 8 | 8 | |
| method of frost | Spray water flooding | |||||||
| service environment | temperature 5~30 Relative humidity<75% | |||||||
| Total power(kw) | 15 | 18 | 22 | 25 | 28 | 33 | 40 | |
| Equipment installation area and hight(m2xm) | 4x2 | 8x2.5 | 15x2.5 | 20x2.5 | 25x2.5 | 30x2.5 | 35x2.5 | |
| type | ZG-12 | ZG-15 | ZG-20 | ZG-25 | ZG-30 | ZG-35 | ZG-40 | ZG-50 |
| Drying oven size(φxL) | 1.3x1.7 | 1.3x1.9 | 1.4x1.9 | 1.5x2.0 | 1.5x2.3 | 1.6x2.3 | 1.7x2.5 | 1.8x2.5 |
| Effective shelf area(m2) | 12 | 15 | 20 | 25 | 30 | 35 | 40 | 50 |
| Shelf working temperature(°C) | -45~60 | |||||||
| Shelf temperature difference(°C) | ±1 | |||||||
| Condenser temperature(°C) | -50~60 | |||||||
| Condenser water catching(Kg) | 150 | 200 | 250 | 300 | 350 | 400 | 550 | 700 |
| The highest vacuum(Pa) | 3 | 3 | 3 | 3 | 3 | 5 | 9 | 13 |
| cooling water(≤25°C)flow(T/h) | 10 | 10 | 15 | 20 | 25 | 25 | 35 | 40 |
| method of frost | Spray water flooding | |||||||
| service environment | temperature 5~30 Relative humidity<75% | |||||||
| total power(kw) | 45 | 50 | 60 | 70 | 90 | 110 | 130 | 150 |
| Equipment installation area and hight(m2xm) | 40x2.5 | 40x2.5 | 45x2.5 | 45x2.5 | 50x2.5 | 50x2.5 | 60x2.5 | 60x2.5 |
Application area
1. Food industry
Vacuum freeze dryer could be used in the drying vegetables ,meet,fish,condiment instant food and specialtyetc for keeping the foods original fresh look ,smell ,taste ,shape.The freeze-dryed products can regain watercompetently and could be easily longer stored and less-costly transported.
2. Nutrition and health care industry
Vacuum freeze dryer nurture products such as Royal jelly ,ginseng, terrapin,rainworm., etc are more naturaland orginal.
3. Pharmaceutical industry
Vacuum freeze dryer could be used in the drying of Chinese and western leechdom such as blood serum,bloodplasma,bacterin,enzyme,antibiotics,hormone.,etc
4. Biomedicine reserch
Vacuum freeze dryer could long-termly store blood,bacteria,artery,bones,skin,cornea,nerve tissue and organs ,.etc which can regain water and rebirth competently
The vacuum freeze dry equipment could be designed in accordance with the customer's requirement
welcome to contact me !
don't hesit to chating with me .
