The vacuum freeze dryer is a advanced method of dehydration,whose process takes advantage of the principle of ice crystal's lyopilization under purified vacuum condition ,in which the water inice form on the frozen goods can be directly lyophilized into steam without melting in advance ,thus the goods are dried .
Application area
1. Food industry
Vacuum freeze dryer could be used in the drying vegetables ,meet,fish,condiment instant food and specialtyetc for keeping the foods original fresh look ,smell ,taste ,shape.The freeze-dryed products can regain watercompetently and could be easily longer stored and less-costly transported.
2. Nutrition and health care industry
Vacuum freeze dryer nurture products such as Royal jelly ,ginseng, terrapin,rainworm., etc are more naturaland orginal.
3. Pharmaceutical industry
Vacuum freeze dryer could be used in the drying of Chinese and western leechdom such as blood serum,bloodplasma,bacterin,enzyme,antibiotics,hormone.,etc
4. Biomedicine reserch
Vacuum freeze dryer could long-termly store blood,bacteria,artery,bones,skin,cornea,nerve tissue and organs ,.etc which can regain water and rebirth competently
The vacuum freeze dry equipment could be designed in accordance with the customer's requirement
Equipped with water ring pump capable to eliminate residual water inside the chamber.
| The data of freeze drying machine | ||||||||||
| Model | ZG-1 | ZG-2 | ZG-3 | ZG-5 | ZG-10 | ZG-15 | ZG-20 | ZG-30 | ZG-40 | ZG-50 |
| Dying box' s dimension(D*L) |
0.7*0.7 | 0.8*0.9 | 0.9*1.0 | 1.0*1.2 | 1.2*1.5 | 1.3*1.9 | 1.4*1.9 | 1.5*2.3 | 1.7*2.5 | 1.8*2.5 |
| Effective drying plank' s area(M 2 ) | 1 | 2 | 3 | 5 | 10 | 15 | 20 | 30 | 40 | 50 |
| Drying plank' s working tempreture | -45- 60 | -45-60 | -45-60 | -45-60 | -45-60 | -45-60 | -45-60 | -45-60 | -45-60 | -45-60 |
| Drying plank' s difference in tempreture |
± 1 | ± 1 | ± 1 | ± 1 | ± 1 | ± 1 | ± 1 | ± 1 | ± 1 | ± 1 |
| Condensator' s tempreture | -50--60 | -50--60 | -50--60 | -50--60 | -50--60 | -50--60 | -50--60 | -50--60 | -50--60 | -50--60 |
| Condensator' s water-catching weight(kg) | 12 | 25 | 40 | 60 | 120 | 200 | 250 | 350 | 550 | 700 |
| Max working vacuum perssure(Pa) | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 9 | 13 |
| Cooling water' s flox(≤ 25)(T/H) | 2 | 3 | 5 | 5 | 8 | 10 | 15 | 25 | 35 | 40 |
| Mothed of defrosting | SPRAY AND FLOODING | |||||||||
| Working condition | 5-30 | Humidity< 75% | ||||||||
| Maching-assembling power(kw) | 18 | 22 | 25 | 28 | 40 | 50 | 60 | 90 | 130 | 150 |
| Setting dimension(M 2 *M) | 8*2.5 | 15*2.5 | 20*2.5 | 25*2.5 | 35*2.5 | 40*2.5 | 45*2.5 | 50*2.5 | 60*2.5 | 60*2.5 |
Sameples of products
