Specifications
automatic extrusion blow molding machinedouble station
max 2L
milk bottle ocean ball ...
ZK-55Dautomatic blow molding machine
double station blow moulding machine is different from the single station. It has one additional station with high-precision linear guide, covering three major series of PT55D, PTB70D, and PTB90D. the same as single station machines, it can be used to produce a wide variety of materials. Such as PE, PP, PA etc. the largest capacity of the product can be 10L,and its production capacity is 60-70% more than the single station machine. In accordance with different type of products, die heads can be changed to achieve multi-type production.
this machine is double station machine, can have from 1 to 4 heads to meet the demand of different output and different product size for customer. This model is full-automatic process with low noise, saving energy, high efficiency, safe operation, easy maintenance and other benefits. This model is widely used to produce bottles of wine, pesticide, detergent, cosmetic, medicine, mobile oil and other hollow products, such as food containers, toys, balls, chemical barrel, water jug, etc. zk-75D This model can produce max 5L product. ZK-55D max 2L
| technical parameters | ZK-55D | |
| specification | unit | |
| Material | PE, PP, PA,etc | |
| max container capacity | L | 2 |
| number of die | set | 1,2,3,4 |
| output(dry cycle) | pc/hr | 1000*2 |
| machine dimension | M | 2.7*2.3*2.5 |
| total weight | ton | 3.5 |
| clamping system | ||
| clamping force | KN | 38 |
| platen opening stroke | mm | 130-370 |
| platen size | mm | 280*370 |
| max mould size(W*H) | mm | 350*370/250*600 |
| mould thickness | mm | 135-210 |
| power | ||
| max drive | KW | 20.5 |
| total power | KW | 26 |
| fan power for screw | KW | 0.25 |
| air pressure | Mpa | 0.6 |
| air consumption | m3/min | 0.4 |
| average energy consumption | KW | 15 |
| extruding system | ||
| screw diameter | mm | 55 |
| screw L/D ratio | L/D | 24 |
| plasticising capacity | kg/hr | 50 |
| number of heating zone | zone | 3 |
| extruder heating power | KW | 11.6 |
| extruder driving power | KW | 15 |
| die head | ||
| number of heating zone | zone | 2 |
| power of die heating | KW | 4.2 |
| max die-pin diameter | mm | 75 |
| center distance of double die | mm | 130 |
| center distance of tri-die | mm | 110 |
| center distance of tetra-die | mm | 75 |
| accumulator capacity | ML | / |
