Specifications
Practical type, USB high speed interface ,Compatible with various of softwareprofessional manufacturer
Cutting plotter performance features:
·American Professional lntegrated Circuit with high precision and speed.
·Serial port,USB port(optional),Large memory and quick off-line.
·Real time regulation on speed and pressure,setup the origin discretionarily,considering customers at any time.
·Most advanced stamp roller in China,ensure the paper feeding will not deviate for long time,high precision and long life-time.
·Large LCD with Chinese/English character,supporting pre-setup function,operation status is clearly shown.
·Popular cutting language,supporting any kinds of software in the market as FLEXISIGN,SIGNCUT,ARTCUT and cut directly from Coreldraw
·USB system supporting Made-to-order.
Technical Parameter | |||||
Model |
JK361 |
JK721 |
JK871 |
JK1101 |
JK1351 |
Max. Paper Width |
360mm |
720mm |
870mm |
1100mm |
1350mm |
Max. Plotting Width |
270mm |
630mm |
780mm |
1000mm |
1260mm |
N.W/G.W |
8/12kg |
11/20kg |
13/23kg |
15/27kg |
17/32kg |
Measurement(mm) |
605*350*370 |
960*350*430 |
1110*350*430 |
1340*350*430 |
1590*350*430 |
Stand |
None |
Optional |
Yes |
Yes |
Yes |
Operation Environment |
Temperature:5°C ~30 °C Relative humidity:30~ 50% Without condensation |
||||
Interfaces |
Serial Port USB optional |
||||
Cutting Tool |
Imported hardness alloy steel blade |
||||
Language Format |
DMPL / HPGL |
||||
Power Supply |
AC90V-AC260V |
||||
Negative Pressure Adsorption |
Yes |
||||
Cutting Blade Soft Landing |
Yes |
||||
Origin Point Setup |
Yes |
||||
Hefei Kaxing Digital Control Equipment Co., Ltd is the recognized leading manufacturer in China. Founded in 2004, we focus on the design, innovation and manufacturing of CNC products. We proudly supply our customers in Egypt, Vietnam, Thailand, India, Japan, Bulgaria, Serbia, and France with outstanding CNC routers, engraver, laser engraving machines and cutting plotter.
