vinyl cutting plotter/CE&ROHS 1350 mm luxurious type

Specifications

cutting plotter,CE & ROHS
JK1351HE,luxurious type
max plotting width 630mm
USB
compatible with FlexiSIGN,CorelDRAW,Signcut

cutting plotter character :

High strength aluminium alloying structurestreanmlined design ,beautifully and gracefully
Unique cutting blade soft landing function,cutting more freely
Luxurious push&pull vinyl basket,convenient for practical operation.
With USB high speed interface,supporting plug in and off when power is on ,PNP
Imported thin film controlling panel with nine keys ,easy to operate .
Linear bearing carriage with high precision ,high temperature resistant and never deformed characters,easily cut out 3M super thick reflective sheet

luxurious type	JK361HE	JK721HE	JK-871HE			JK-1101HE	JK-1351HE
stand	no	yes	yes			yes	yes
max.paper width	360mm	720mm	870mm			1100 mm	1350mm
max.plotting width	270mm	630mm	780mm			1000 mm	1260mm
memory	1/4M
net weight/gross weight	8/12kg	11/20kg			12/24kg	14/27kg	17/32kg
packing size	66*38*38 cm	101*38*44  cm		116*38*44 cm		139*38*44 cm	164*38*44 cm
interface	Serial port&USB port(optional)
power supply	switching power supply
max.plotting speed	800mm/s
max.cutting force	500 G
carriage	metal carriage
mechanical resolution	0.0254mm
language format	DMPL/HPGL
cutting tool	imported hardness alloy steel blade
power supply	AC90V-240V
operation environment	temperature:5°c-35°c relative humidity:(305-50%)without condensation
colors	white,grey,black

Packed in Double-layer carton 164*38*44 cm 32 KGS

1. One year warranty

2. Customized special machine with your LOGO

Hefei Kaxing Digital Control Equipment Co., Ltd is the recognized leading manufacturer in China. Founded in 2004, we focus on the design, innovation and manufacturing of CNC products. We proudly supply our customers in Egypt, Vietnam, Thailand, India, Japan, Bulgaria, Serbia, and France with outstanding CNC routers, engraver, laser engraving machines and cutting plotter.
