Specifications
1.pull and drive.2.the diesel:S1100,but optional
pact construction and easy to travel.
4.cultivate, spray ,sow and reap
- Machine model:FL151
Type: pull and drive.
Overall dimensions(L×W×H): 2200×1250×1220mm
Wheel tread: 680~1000mm(stepless shift,adjustable)
minimum ground clearance: 258mm
Minimum working weight: 400kg
Transmission gear box: equipped with main transmissions and sub transmissions,6 forward gears and 2 reverse, full power sliding gear transmission,consists of (3+1) ×2 cylindrical wheel gear
gears:
forward |
1 |
speed(km/h) |
3.5 |
rated traction(N) |
1970 |
2 |
speed(km/h) |
6.4 |
rated traction(N) |
1970 |
|
3 |
speed(km/h) |
10.4 |
rated traction(N) |
1970 |
|
4 |
speed(km/h) |
12.6 |
rated traction(N) |
1970 |
|
5 |
speed(km/h) |
21.3 |
rated traction(N) |
1740 |
|
6 |
speed(km/h) |
27.7 |
rated traction(N) |
1000 |
|
reverse |
1 |
speed(km/h) |
2.6 |
rated traction(N) |
/ |
2 |
speed(km/h) |
7 |
rated traction(N) |
/ |
Connection of engine and clutch: belt transporter
Starting mode: rotate the hand crank
2.engine model: S1100
type/style: horizontal, single cylinder, four stroke and water cooled
engine bore and stroke: 100×115mm
engine displacement: 0.903L
engine pressure ratio: 17:1
rated power: 11.03KW
rated rotating speed: 2200r/min
type and model of fuel injection pump: shifting fork type, BF1AK90
type of air filter: paper air filter
type of cooling system: evaporative cooling or water-cooled, optional
3.capacity of fuel tank: 9L
4.drive wheel tyre: 6.00-16
5.tire pressure of drive wheel: 120~250KPA
