Fully automatic and high speed waste paper recycling production line machine
This Fully automatic and high speed waste paper recycling production line machine mainly produce paper board, corrugated paper and so on.
Specification:
products:one side white board,two sides white board,natural color box board
trim width:1600mm
basis weight:200-400g/m2
working speed:20-60m/min
productivity:20t/d
transmission:AC frequency,sectional control
gauge:2400mm
Main parts of a corrugated paper machine
Headbox:open type headbox/air-cushioned headbox with rectangle-taper manifold,step-hole plate diffuser, distributor roll surface of headbox (incl: distributor roll) exposed to stock is mirror-polished.
Wire section
Comprised of wire frame, walking board, white water pan, forming plate, drainage foil, vacuum drainage foil, wet suction box, suction box, breast roller support and lifter, vacuum couch roller, wire-driving roller, wire-leading roller, compound roller, scraper, spray tube, slitter edge tail cutter, wire tension unit, guide and starch applicator, etc. longish wire is polyester forming wire and replaced in cantilever method. Jack is at the operating side, use jack which is applicable to load.
Sizing part
Note: we have engineers overseas to provide installation and maintenance service for you
1.Pre-sales Service
- Offering comprehensive technical and business consultation services;
- Proposing the most suitable scheme and equipment for our clients;
- Designing and fabricating targeted products according to the special requirements of clients;
- Training periodically high qualified service technician.
2.After-sales Service
- Highly inspecting equipments in every working procedure, quality comes first;
- Fast & Safe Delivery;
- Assisting our clients for foundation construction of equipments;
- Dispatching engineers to install and debug equipments;
- Training the first-line operators on site;
- Regularly visit clients to solve production problems;
- Providing life-long maintenance service;
- Providing technical exchanging;
What do you offer?
A: We can offer the whole pulp and paper production line. From factory design to machine installation and training, our company can supply for you all.
Are your a manufacturer?
A: Yes. Of course we are. We are spealized in pulp & paper equipment manufacturing in China for more than 30 years. There are about 50 paper mills near our factory and most of them are using our machines. So, welcome to visit our factory and I believe you will be satisfied with our products.
What's your advantages?
A: We have more than 30 years experience in the field of papermaking industry.
20000 square meters workshop with more than 200 staffs including 50 engineers.
ISO9001:2000 and BV certification.
Strict quality control of every procedure.
