Home > Lights & Lighting > Emergency Light & Indicator Light > Aviation Obstruction Light > Control Box for Aviation Warning Light

Control Box for Aviation Warning Light

Name: Control Box for Aviation Warning Light
Brand: LANSING
SKU: 110726153
Availability: InStock

Control Box for Aviation Warning Light thumbnail-1

Control Box for Aviation Warning Light photo-1

US$ 0.1 - 499 MOQ: 1 Piece

Key Specifications

Get Latest Price

IP Rating:

IP65

Place of Origin:

Shanghai, China

Brand Name:

LANSING

Contact Supplier Request Quote Chat Now

Shanghai Lansing Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

IP Rating IP65

Place of Origin Shanghai, China

Brand Name LANSING

Model Number CBL04A

Obstruction light control box
Aviation obstacle light controller
Control box for aircraft warning light
navigation controller

CBL04A Control Panel for aircraft warning light

Product Description

CBL04A Control Box employs MCU IC control technology. With a pre-programmed software, CBL04A can control up to 4 aviation obstruction lights. When any light fail, the control box will send a alarm signal to alarm device in BTS in order for maintaneance staff to replace the light immediately. if needed, it can turn on all light in the system and make them flash at the same time. (Control box that can control more than 4 lights are also available upon request).

A photocell is included with the control box, which can turn on/off the system at dawn/dusk. The photocell should be installed in open environment.

CBL04A added a extra surge protection than CBL04. The surge protector can risist up to 65KA, 2.2KV

Functions Features

All lights on/off lights simultaneously
Light failure indication, there are corresponding indicator shows when any light failed
Alarm signal output, can connect to other external alarm devices
A manual photocell switch, which can switch to manual control mode during installationing
External automatic photocell
The controller is indoor type (out-door type available upon request)

Description	Parameter
Operation voltage	Input: 18-65VDC, 110-240VDC
	Output: 18-65VDC
Serge protection	65KA/2.5KV
Power frequency	50-60HZ
Power consumption	Support up to 300watts
Photocell sensitivity	30-70lux(optional)
flashing	20-60 times/min(optional)
Ambient Temperature	-30-60C
Size	306203113mm

Company Information

Design, Quality and Value have made "LANSING" Lighting the partner of choice in the lighting industry over the past few years. "LANSING" products are built to last long, achieved through a high degree of craftsmanship, with lighting engineering experience.

The Entire product range is designed and fabricated by our expert team of professionals, who have strong technical and business skills. With the support of modern infrastructure and well qualified team, we are able to provide customized lighting products in the market. Satisfying the client's precise needs has been our foremost priority and we have formulated competitive price policy to meet this objective. We at "Lansing" Believes in strengthen our Team & resources and detail R&D engineering which enable us to know how to work with attention on the quality of details, customized solutions, customer care and support. Our offered products are widely used in telecommunication network, harbor,wind turbine, production factories etc industries.

There are many outstanding features that define Lansing brand: Customized solutions, reliability, Performance, Quality with competitive price. This defines our USP(Unique selling proposition).
