GIS Sealing End
Introduction:
48/66kV, 64/110kV, 76/132kV, 127/220kV, 290/500kV
Model No.: YJZGG, YJZGG(D)-B
Test Standard:
IEC60859 IEC62271-209
Each product will carry out the routine test in high-voltage lab of the company
a. Partial discharge test b. Voltage withstand test
The product is XLPE cable indoor termination, and suitable for GIS switchgear / transformer. The GIS termination consists of EPDM stress cone, stress cone bracket, Epoxy busing, connector and wiping sleeve. We have both assembly type and plug-in type.
The Main Feature:
The stress cone is made of imported EPDM. The surface pressure between the stress cone and the epoxy bushing is maintained by the spring device(stress cone bracket) so that the press of interface is kept permanently during the course of running. This structure can overcome the disadvantage or defect from material aging.
The termination is whole dry type, no oil, eliminate the problem of leakage.
Compact, lightweight, and small volume
The connecting between termination and cable is plug-in type, easy to install and maintain.
Plug-in type GIS termination suit to the connection between power cable and transformer. It cancel the oil/oil bushing or oil/gas bushing and save a lot of space.
Add connector to short type plug-in GIS termination, it can used in GIS equipment (long type GIS termination kits).
.
Rated voltage applicable cable dimension
| Rated Voltage | Cable Section |
| 66kV | 150-1600mm2 |
| 110kV | 240-2000mm2 |
| 138kV | 240-2000mm2 |
| 220kV | 240-3000mm2 |
| 500kV | 800-3000mm2 |
When ordering, please state the following data:
1). Voltage
2). Conductor material copper or aluminum
3). Conductor cross section diameter
4). Diameter of insulation
5). Outer diameter of cable
Quality warranty & after sales service:
1. Secure prodction under ISO9001 & ISO14001 and OHSAS 18001 system;
2. 2-year warranty;
3. Can provide service of installation or training your installation workers.
4. Service Life: 30 years
