Cable Sheath Surge Voltage Limiter
Negotiable
MOQ: 50 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
changlan
Model Number:
ZJD-N ZJD-W
Payment & Shipping
Payment Methods:
Port of Shipment:
any port in china
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Hunan, China
Brand Name
changlan
Model Number
ZJD-N ZJD-W
Specifications
cable sheath surge voltage limiter:1. type: FBY-6 and FBY-12
2. to protect the cable insulation from breakdown by voltage
Cable sheath surge voltage limiter :
Application: used for limiting the induced over-voltage of cable metal sheath and protect the cable insulation from breakdown
Technical data:
No. |
Testing item |
Type and technical requirement |
|||
FBY-6 |
FBY-12 |
||||
1 |
1mA DC referring voltage (kV) |
≥3.8 |
≥4.5 |
≥7.6 |
≥9 |
2 |
0.75U1mA leakage current(μA) |
≤30 |
|||
3 |
2ms square wave current impulse 18 times(A) |
600A |
|||
4 |
8/20μs impulse current 10kA residual voltage(kV) |
≤7 |
≤9.5 |
≤14 |
≤19 |
5 |
4/10μs large current impulse 2 times(kA) |
100 |
|||
6 |
Residual voltage rate |
K≤2 |
K≤2.5 |
K≤2 |
K≤2.5 |
