Overview
Dibsys provides the advanced and powerful encoder and decoder for the P2P system, And according to different requirement of different project can flexibly configurate the different encoder and decoder of the P2P system. It mainly include SD assortment, HD assortment, Full HD assortment, Multi-audio assortment.
Comparisons
The full HD assortment
Product details
|
Item |
MPEG-2/H.264 SD/HD encoder (ENC3411 plus)
|
Professional Full HD decoder (IRD1301)
|
|
Input |
Video input |
1x SD/HD-SDI |
1x Tuner (option DVB-T2/S2/S/C/T/DTMB/ATSC/ISDB-T) |
1x HDMI | |||
1x CVBS | |||
1x YPbPr | |||
Audio input |
4x XLR |
1x IP |
|
4X RCA |
1x ASI |
||
1x AES |
2x DVB- CI slot |
||
Output |
1x IP
|
1x HDMI |
|
1x CVBS | |||
1x SD/HD-SDI | |||
2 pairs of ASI | |||
2 identical ASI |
YPbPr |
||
TS/IP | |||
AES/EBU Audio | |||
Video format |
MPEG-2/MPEG-4 AVC(H.264) HP@L4, MP@L3 |
MPEG-2 and MPEG-4 AVC/H.264 |
|
Audio format |
MPEG-1 layer 2, AAC, AC3 passthrough |
MPEG-1 layer2, AAC |
|
Audio Channel |
4 stereo or 8 Mono |
2 pairs of stereo audio
(8 Audio PIDs decode in SDI out, 6 Audio PIDs decode in AES out
|
|
Resolution |
1920x1080i,1280x720p,720x480I,720x576I |
1080i ,720p ,576i,,480i |
|
Protocol |
UDP/RTP |
UDP/RTP |
|
Chroma |
4:2:2/ 4:2:0 |
4:2:0 , 4:2:2(option) |
|
Closed Caption |
Supported |
Supported |
|
BISS |
Not support |
Supported |
|
