Free to Air and Encryped satellite receiver dvb-s Transcoder with wowza,Adobe Flash server

Description

MultiStreamer  DVB-S2/IPTV Transcoder

ENC3580  Receiver Transcoder

Inputs

8 FTA DVB-S2 RF

4 decrypt DVB-S2 RF

Up to 20 MPEG-TS IP (Two GbE IP ports)

6 FTA DVB-S2 RF

4 decrypted DVB-S2 RF

Up to 8 MPEG-TS IP (One GbE IP ports)

Outputs

Two GbE IP ports

One GbE IP ports and ASI ports

Codec formats

MPEG-2 to H.264/MPEG4

H.264/MPEG4 to MPEG-2

H.264/MPEG4 to H.264/MPEG4

H.263

MPEG-2 to H.264

H.264 to MPEG-2

Channels

Up to 20SD,8-10 720P,5-6 1080P streams

Up to 8SD,4 720P, 4 1080i/p streams

Audio format

MPEG-1 Layer II,AAC,AC3

MPEG-1 Layer II,AAC,AC3 passthrough

Resolutions

HD,D1, SQVGA, QCIF, QVGA,SIF, VGA,

or any custom size up to 1080P

1920x1080I,1440x1080I,1280x720P,960x540p,

854x480p,720x576i, 720x480i, 480x576,

544x576, 640x576,704x576,640x360

Video Bitrate for

 Good quality

Ultra-Low bitrate

500-800kbps@SD,800-1500Kbps@720p

2000-4000kbps@1080p

Low bitrate

1000-1500kbps@SD,1800-3500kbps@720p

3000-5000kbps@1080i

Protocols

RTMP/RTSP/RTP/HTTP/HLS/UDP

UDP/RTP

Chipsets

Embeded Linux(Intel CPU)

VIXS

Cost per channel

Low cost

Ultra-Low cost

Video quality

Superior quality

Good quality

Subtitle and closed

caption support

-

Teletext, VBI subtitling, CEA608, and CEA 708

Steams out

multiple profiles and protocol and bitrate can be created per input

only One stream out per input

Customers

Mobile operators,Content/Service providers,

digital Broadcasters(Need strickly video bitrate in limited BW)

Deploying Wowza,Adobe,Microsoft,Apple

Mediaroom etc

Cable,DTH Broadcasters

IPTV(not need strickly video bandwidth,The server can supported UDP/RTP protocol)

Deploying Wowza server and which server supported mpeg2 ts
