RG405 Cable Assembly With MMCX Male Right Angle Connectors
US$ 1.88 - 2.34
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Four Star
Model Number:
MMCX-JWB2/MMCX-JWB2-300
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
60mm RG405 Cable Assembly With SMA Male to MCX Male ConnectorsUS$ 1.46 - 1.93MOQ: 100 Pieces -
RG405 Cable Assembly With SMA RP-Male to MMCX Male ConnectorsUS$ 1.48 - 1.95MOQ: 100 Pieces
-
RG405 Cable Assembly With MCX Male ConnectorsUS$ 1.56 - 2.02MOQ: 100 Pieces
-
RG223 Cable Assembly With SMA Male Crimp to N Male Crimp ConnectorsUS$ 2.95 - 3.41MOQ: 100 Pieces
-
RG223 Cable Assembly With N Male Right Angle Crimp to N Female Bulkhead Crimp ConnectorsUS$ 4.03 - 4.5MOQ: 100 Pieces
Place of Origin
Jiangsu, China
Brand Name
Four Star
Model Number
MMCX-JWB2/MMCX-JWB2-300
Type
Coaxial
Number of Conductors
1
Product Description
| 300mm RG405 Cable Assembly with MMCX Male Right Angle Connectors On Both Ends | ||
| Model No. | MMCX-JWB2/MMCX-JWB2-300 | |
| Connector Type | A Side:MMCX Connector Male Right Angle for RG405 Cable | |
| B Side:MMCX Connector Male Right Angle for RG405 Cable | ||
| Cable Type(Name) | RG405 Cable | |
| Cable Length | 300mm (Customized Length Available) | |
| Connector Interface | IEC 60169-15; IEC 61169-36 | |
| Typical Frequency Range | DC-6GHz | |
| VSWR | ≤1.30@DC-6GHz | |
| Intermodulation 3rd (PIM3) | — | |
| Durability | ≥500 cycles | |
| Parts Name | Material | Plating |
| Body | Brass | Au |
| Insulator | PTFE | — |
| Inner Conductor | Phosphor Bronze | Au |
| Coupling Nut | Brass | Au |
| Operating Temperature | _45 ℃-85 ℃ | |
| Weatherproof Rate | IP67 | |
| RoHs (2002/95/EC) | Compliant by exemption | |
