Home > Products > BTS Passive Components > rf coaxial fixed attenuator N male to N female connector 5 Watt
rf coaxial fixed attenuator N male to N female connector 5 Watt
USD $3.8 - $9.9
/ Piece
30 Pieces(Min.Order)
- 30000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card
You May Like
- RF Testing Wire Cable Assembly SMA Male Female connector
- 50 Watt Dummy Load/Termination Low PIM3 -150dBc N male/female
- high power good PIM -150dBc RF Coaxial Fixed Dummy Load/Termination 200W
- good low PIM3 -150dBc RF Coaxial Fixed Dummy Load/Termination 50W
- 800-2500MHz 3x2 3 in 2 out Hybrid Combiner n female type DC-3Ghz
- RF 800-2700MHz 2 in 1 out 2x1 3dB Hybrid Coupler Combiner N Female type
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Four Star | Model Number: | FS.ATT-03XX-051401 |
Product Description
Product Description
Model No. | FSATT-03XX-N5P (XX Indicates ATT Value) | |||||||
RF Connector | N Male/N Female | |||||||
Operating Freq. | DC –3GHz | |||||||
Average Power | 5Watt | |||||||
Peak Power | 5µs:0.2KW | |||||||
VSWR | ≤1.15 | |||||||
Intermodulation 3rd | ≤ -120dBc@2×20W | |||||||
Attenuation Value | 3dB | 5dB | 6dB | 10dB | 15dB | 20dB | 30dB | |
Accuracy | ±0.3dB | ±0.5dB | ±0.5dB | ±0.7dB | ±0.7dB | ±0.8dB | ±0.8dB | |
Material an Plating | ||||||||
Parts Name | Material | Plating (Finish) | ||||||
Connector body | Brass | Ni/Tri-Metal(CuZnSn) | ||||||
Insulator | PTFE | — | ||||||
Inner Conductor | Phosphor Bronze | Ag | ||||||
Housing | Aluminum | Black Passivation | ||||||
Operating Temp. | _45~ 85 ℃ | |||||||
Storage Temp. | _60~120℃ | |||||||
Weatherproof Rate | IP66 | |||||||
Relative Humidity | 5%-95% | |||||||
RoHs (2002/95/EC) | Compliant by exemption | |||||||
Weight (Net) | 85g |
